4-нм быстродействующий привод 24 В моторизованный демпфер для системы

Item

S6061-04DN(F)K/24V

S6061-04DN(F)K/230V

Torque

Nm

4

Damper area

m²

1

Running time

sec

4

Power supply

V

24VAC/DC ;110-250VAC

Frequency

Hz

50/60Hz

7.5W 50/60Hz

Running consumption

W

7.5W(24V);10.5W(220V)

Maintaining

consumption

W

0.5W(24V);2.5W(220V)

Weight

Kg

1.Kg

Control signal

2/3 point

Rotation angle

0~90º(Max 93°)

Limited angle

5~85º(Per step 5º)

Auxiliary switch rating

3(1.5)Amp 250V

Life cycle

>70000 cycles

Noise level

45dB(A)

Electrical level

Ⅱ

Protection level

IP44 or IP54

Temperature

-20~+50℃

Humidity

5~95%RH

Storage temperature

-40~+70℃

Certificate

CE

CE  UL
