Product Description
Specification
SPECIFICATION | TKEM-M1 1KW/1280WH | TKEM-M2 1KW/2560WH | TKEM-M3 2KW/2560WH | ||
INVERTER/CHARGER | |||||
Inverter Type | 1KW/25.6V | 1.2KW/25.6V | 2KW/51.2V | ||
Rated Output Power | 2KW | 2.4KW | 4KW | ||
Output Voltage Waveform | Pure Sine Wave | 230VAC | |||
Output Voltage | 230VAC | ||||
Low DC Warning Voltage | 22.4Vdc | 44.8Vdc | |||
Low DC Cut-off Voltage | 21.6Vdc | 43.2Vdc | |||
Low DC Warning Return Voltage | 22.4Vdc | 44.8Vdc | |||
Total Charging Current(Grid+solar) | 20A Max. | 20A Max. | |||
Bulk Charging Voltage | 29.3Vdc | 58.6Vdc | |||
Float Charging Voltage | 28.8Vdc | 57.6Vdc | |||
LITHIUM IRON BATTERY | |||||
Normal Battery Modular | 25.6V50Ah | 25.6v 100ah | 51.2v 50ah | ||
Normal Capacity (25°C,0.2C) | 1280Wh | 2560 Wh | |||
Nominal Battery Voltage | 25.6Vdc | 51.2Vdc | |||
Max.Charge Current | 60A | ||||
Max.Discharge Current | 60A | ||||
Operation Voltage Range | 22.4Vdc~29.2Vdc | 40V-58.4V | |||
Operation Temperature | -23°C~+65°C | ||||
AC INPUT | |||||
Nominal Input Voltage | 230Vac | ||||
Low Loss Voltage | 170Vac +7(UPS),90Vac+ 7(Appliances | ||||
Low Loss Returm Voltage | 180Vac土7(UPS),100Vac7(Appliances | ||||
High Loss Voltage | 250Vac土7 | ||||
High Loss Returm Voltage | 260Vac土7 | ||||
Max. AC Input Voltage | 265V ac | ||||
Nominal Input Frequency | 50HZ | ||||
AC Charging Current | 20AMax | ||||
SOLAR INPUT | |||||
Nominal PV Voltage | 36Vdc | ||||
PV Array MPPT Voltage Range | 30Vdc~60Vdc | ||||
Max. PV Array Open Circuit Voltage | 60Vdc | ||||
Solar Charging Current | 10A Max. | ||||
PRODUCTS SIZE(mm) | 432*190*395 | 432*190*395 | updating | ||
Cartoon size (mm) | 500*260*465 | 500*260*465 | updating | ||
PROTECTION | |||||
Protection | Overcharge protection 、Overdischarge protection 、Overcurrent 、protection. | ||||
AMBIENT | |||||
Noise(dB) | <30°C < 40dB (1 meter) | ||||
Working Temperature | -23°C~+65°C | ||||
Humidity | 0~95%( no condensation) | ||||
Sea Level(m) | <1500 | ||||
OTHERS | |||||
Effeciency | 92.0% | ||||
