Product Description


tv studio equipment broadcast H-DMI SDI IP 10x optical zoom ptz camera USB3.0 video conference camera
Connectivity, creativity, and control of your video is easier than ever using your existing network infrastructure when you
implement Video. Today, you have compelling new opportunities to engage in visual storytelling within practically any environment.. with EZOLEN PTZ UHD 4K Color Video Conference Camera


4K Ultra HD
It adopts a new generation of SONY, which can realize 4K (3840x2160) ultra-high-resolution high-quality images. And backward compatible with multiple resolutions such as 1080P and 720P.
H.265 Support
The first H.265 encoding support conference video camera in the world, enabling UHD 2160p video stream by ultra-low bandwidth.
Advanced autofocus technology
Utilizing advanced focusing algorithms and TOF module assistance, the lens quickly, accurately, and stably achieves focus.
Smart Exposure
Effectively solve the impact of projectors, televisions and other equipment on shooting people.
AAC Audio Encoding
Support AAC audio encoding, better sound quality and smaller bandwidth.
Low illumination
The new CMOS image sensor with ultra-high performance-to-noise ratio can effectively reduce image noise in low illumination conditions, while applying 2D and 3D noise reduction algorithms to greatly reduce image noise, even in ultra-low illumination conditions, still keeping the picture clean and clear , The image signal-to-noise ratio is up to 50dB or more.
Single-lens human tracking
With the camera’s AI capabilities and advanced AI algorithms, it enables single-lens human tracking, allowing for automatic tracking in education, conference, and live streaming scenarios.
Abundant & Perfect Interface
Support USB3.0, 3G-SDI, H-DMI, IP output. USB3.0, 3G-SDI, HDMI, LAN channels can simultaneously output high-definition digital signals.
Remote Control
Using RS232/485 interface, all the parameters of the camera can be remote controlled bythe high-speed communications.


Model No.
UVX410K-USH
UVX412K-USH
UVX420K-USH
Sensor
1/2.5-inch high-quality CMOS sensor, 8.51 Megapixels

Lens
10x optical zoom
f=5.7(W)~57mm(T)
F1.6～F3.5
12x optical zoom
f=4(W)~48mm(T)
F1.6～F3.5
20x optical zoom
f=5.5(W)~110mm(T)
F1.6～F3.5
HOV
55° (wide end) ~ 5.5° (tele end)
70° (wide end) ~ 5.9° (tele end)
58° (wide end) ~ 2.9° (tele end)
Video Out
H-DMI +SDI + IP + USB3.0


Camera Optical Lens Parameter
Sensor
1/2.5-inch high-quality CMOS sensor,
8.51 Megapixels
Effective Pixels
Effective Pixel: 8.51M
Resolution
UHD: 4KP30/4KP25

FHD:
1080P60/1080P50/1080P30/1080P25

HD:
720P60/720P59.94/720P50


Camera Optical Functions
Focus
Auto, Manual
Min Illumination
0.1lux (F1.6, AGC ON, color)
0.001lux (F1.8, AGC ON, black-white)
Shutter Speed
1/30s ~ 1/10000s
AGC
Auto, Manual
White Balance
Auto, Indoor, Outdoor, One Push, Manual, Specified color temperature
Exposure
Auto, Manual, Shutter Priority, Iris Priority
SN Ratio
≥55dB
DNR
2D/3D
BLC
Yes


Interface
HD Output
1*H-DMI
Video Interface
1*3G-SDI: BNC type, 800mVp-p, 75Ω, Along to SMPTE 424M standard
1*USB3.0
Network Interface
1xRJ45: 10M/100M Ethernet Interface
Audio Interface
1-ch: 3.5mm Audio Interface, Line In
Communication Interface
1xRS232 In: Max Distance: 30m, Protocol: VISCA/Pelco-D/Pelco-P
1xRS422: Max Distance: 1200m, Protocol: VISCA/Pelco-D/Pelco-P


IPC Features
Video Compression
H.265/H.264/MJEPG
Video Stream
Main Stream, Sub Stream
Main Stream Resolution
(3840*2160, 1920*1080, 1280*720)
Sub Stream Resolution
(704*576, 640*480, 640*360, 576*480, 352*288, 320*240, 320*180) 25/30fps
Video Bit Rate (NDI®|HX)
32Kbps ~ 20480Kbps
Video Bit Rate
32Kbps ~ 20480Kbps
Bit Rate Type
Variable Rate, Fixed Rate
Frame Rate
50Hz: 1fps ~ 50fps, 60Hz: 1fps ~ 60fps
Audio Compression
AAC, G711
Audio Bit Rate
96Kbps, 128Kbps, 256Kbps
Support protocols
TCP/IP, HTTP, RTSP, RTMP/RTMPS,SRT, Onvif, DHCP, Multicast, GB/T28181,etc.




Installation Process






Applications






Certifications




Company Information




FAQ


Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A:Sample needs 1-3 days, mass production time needs 5-10 days for order quantity more than



Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 1pc for sample checking is available



Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.



Q5. How to proceed an order?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places formal order.
Fourthly We arrange the production.



Q6. Is it OK to print my logo on product?

A: Yes. Please inform us formally before our production and confirm the design.



Q7: Do you offer guarantee for the products?

A: Yes, we offer 2 years warranty to our products.



Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will supply replacement or repair services according to real situation.
