Внешняя коммерческая реклама цифровая СВЕТОДИОДНАЯ панель экран рекламный щит для мобильного грузовика
- Категории: >>>
- Поставщик: Shenzhen,Musen,Display,Technology,Co.,Ltd.Shenzhen,Ltd.
Поделиться:
Описание и отзывы
Характеристики
ITEM | P1.953 | P2.5 | P2.604 | P2.976 | P3.91 | P4.81 | |||||
Pixel Pitch (mm) | 1.953 | 2.5 | 2.604 | 2.976 | 3.91 | 4.81 | |||||
LED Encapsulation | SMD1515 | SMD1515 | SMD2020 SMD1415 | SMD2020 SMD1415 | SMD2121 SMD1921 | SMD2121 SMD1921 | |||||
Module Resolution (pixels) | 128x128 | 100x100 | 96x96 | 84x84 | 64x64 | 52x52 | |||||
Module Size (mm) | 250x250 | ||||||||||
Panel Resolution (pixels) | 256x256 | 200x200 | 192x192 192x384 | 168x168 168x336 | 128x128 128x256 | 104x104 104x208 | |||||
Weight (kg/pcs) | 7.5/14 | 7.5/14 | 7.5/14 | 7.5/14 | 7.5/14 | 7.5/14 | |||||
Physical Density (pixels/㎡) | 262144 | 160000 | 147456 | 112896 | 65410 | 43264 | |||||
Optimum Viewing Angle | H:160° V:160° | ||||||||||
Optimum Viewing Distance (m) | >2 | >3 | >3 | >3 | >4 | >5 | |||||
Input Voltage | 110-220V AC±10% | ||||||||||
Max. Power Consumption (W/㎡） | 500-720 | ||||||||||
Avg. Power Consumption (W/㎡） | 250-360 | ||||||||||
Brightness (cd/㎡) | 600 Indoor | 800 Indoor | 1000 Indoor 4500 Outdoor | 1000 Indoor 5000 Outdoor | 800 Indoor 4500 Outdoor | 800 Indoor 5000 Outdoor | |||||
Refresh Frequency (Hz) | 3840 | ||||||||||
Frame Frequency (Hz) | 50-60 | ||||||||||
Grayscale (bit) | 14-16 | ||||||||||
Operating Tempreture/Humidity (℃/RH) | -10℃~40℃ / 10~80%RH | ||||||||||
Advantages
1. Can lift 1000MM, can rotate 360 degrees.
2. Equipped with solar panels and converters and 9600AH battery, can achieve continuous power supply LED screen.
3. With brake device
4. Trailer lights with EMARK certification, including turn signals, brake lights, turn signals, side lights.
5. With 7 core signal connection head
6. With tow hook and telescopic rod
7. Two tire fenders
8. 10mm safety chain,80grade rated ring
9. Reflector,2white front,4yellow sides,2red rear
10. The whole vehicle galvanized process
11.Brightness control card, automatically adjust brightness
12. VMS can be controlled wirelessly or wired
13. Users can remote control LED SIGN by sending SMS messages.
14. Equipped with GPS module, can remotely monitor the position of VMS.
product name | Multi-dimensional customized LED display is acceptable |
product classification | Spherical, round, horn shaped LED display, LED display for rent, more LED display |
product size | customizable |
Recommend Products
Q1. Can I have a sample order for led Screen?
A: Yes, we welcome sample order to test and check quality. Both for LED module or
a whole screen.
Q2. What about the lead time?
A: About 7~10 working days.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1 square meter or a module checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We mostly accept FOB train term, but we can help you order and arrange shipping agent
It usually takes 20 to 30 days on sea. a few days for customer clearance
Q5. How to proceed an order for led Screen?
A: Firstly, let us know your requirements or application.
Secondly, we quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products.
Q7: How to deal with the faulty?
A: Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
A: Yes, we welcome sample order to test and check quality. Both for LED module or
a whole screen.
Q2. What about the lead time?
A: About 7~10 working days.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1 square meter or a module checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We mostly accept FOB train term, but we can help you order and arrange shipping agent
It usually takes 20 to 30 days on sea. a few days for customer clearance
Q5. How to proceed an order for led Screen?
A: Firstly, let us know your requirements or application.
Secondly, we quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products.
Q7: How to deal with the faulty?
A: Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
