HW-920 Separated DTH Surface Drill Rig
Product Description
HW-920 Separated DTH Surface Drill Rig
* Widely used in various surface mines, quarries & construction work sites, etc. Hole range of 110 - 138 mm. The machine has a low body, a new housing design, and a body leveling function, and the product has strong stability.rock mine drill rig road tunnel drilling machine jumbo drilling machine\t
* Widely used in various surface mines, quarries & construction work sites, etc. Hole range of 110 - 138 mm. The machine has a low body, a new housing design, and a body leveling function, and the product has strong stability.rock mine drill rig road tunnel drilling machine jumbo drilling machine\t
Specification
Features:
* The own rotation unit driven by double cycloid motor for more powerful rotation and less drill tools jamming.rock mine drill rig road tunnel drilling machine jumbo drilling machine\t
* 2.Standard equipped with plunger piston motor for greater climbility and more reliable quality.
* 3.Standard equipped with box type tramming beam and international standard construction machinery tramming tracks.rock mine drill rig road tunnel drilling machine jumbo drilling machine\t
* 4.Equipped with the own developed dry dust collection system for high efficiency & more eco-friendly.
Rig Model | Power | Rated Power | |
HW425 | YuchaiYC4DK-80 | 58 kW | |
Hole Depth | 30 m | ||
Drill Pipe Sizes | 76 *3,000 mm | ||
Hole Dia | 110 -138 mm | ||
Hammer | 4"/5" | ||
Rotation Torque(Max.) | 3,200 N.m | ||
Rotation Speed | 0 -100 rpm | ||
Working Pressure | 0.7-2.5Mpa | ||
Length of Feed Beam | 5,645 mm | ||
Feed Travel Length | 3,660 mm | ||
Feed Extension | 960 mm | ||
Feed Speed | 26 m/min | ||
Feed Force | 20 kN | ||
Pull Up Force | 45 kN | ||
Feed Type | Chain & Cylinder | ||
Tramming Speed (Max.) | 2.5 km/h | ||
Gradient | 25° | ||
Ground Clearance | 280 mm | ||
Total Weight | 6,230 kg/6,500kg | ||
Transportation Dimensions | 7,000 *2,250 * 2,700mm | ||
