Product descriptions from the supplier
Overview
Product Description
Product features:
1. The filter is composed of different specifications of corrugated mesh, staggered in the inner frame;
2. Reduce the gaps between aluminum mesh for better filtration;
3. For acidic, alkaline, or high-temperature environments, stainless steel or stainless steel corrugated mesh can be selected for production;
4. Large air volume, low resistance, reusable for cleaning and long service life External frame selection (aluminum frame, galvanized frame, aluminum plate folding frame, stainless steel frame)
Filter material material (aluminum mesh, stainless steel mesh)
2. Reduce the gaps between aluminum mesh for better filtration;
3. For acidic, alkaline, or high-temperature environments, stainless steel or stainless steel corrugated mesh can be selected for production;
4. Large air volume, low resistance, reusable for cleaning and long service life External frame selection (aluminum frame, galvanized frame, aluminum plate folding frame, stainless steel frame)
Filter material material (aluminum mesh, stainless steel mesh)
Application field:
Used for central air conditioning range hoods, primary filtration, special acid and alkali resistant ventilation filtration
Type | Size（mm） （WxHxT） | Rated Airflow(m3/h) | Initial Pressure Drop (Pa) | Average Arrestance | Note |
DH-JSCX | 295*595*21 | 800 | 15 | G2/65% | 21mm thick corrugated mesh with three layers and one layer of stainless steel fine mesh, 25mm thick corrugated mesh with four layers and one layer of stainless steel fine mesh, 46mm thick corrugated mesh with seven layers and one layer of stainless steel fine mesh |
495*495*21 | 1300 | 15 | G2/65% | ||
595*595*21 | 2200 | 15 | G2/65% | ||
295*595*25 | 1000 | 18 | G2/65% | ||
495*495*25 | 1500 | 18 | G2/65% | ||
595*595*25 | 2600 | 18 | G2/65% | ||
295*595*46 | 1500 | 25 | G2/65% | ||
495*495*46 | 2200 | 25 | G2/65% | ||
595*595*46 | 3200 | 25 | G2/65% |
1. Question: Are you a manufacturer or a trader? Where is your factory located?
We are a manufacturer of professional designers and engineers. Our factory is located in Guangzhou city.
2. Question: How long is your warranty period? Can we expand?
Answer: 12 months after installation and debugging. The warranty can be extended at an additional charge.
3. Question: Do you have a professional team of engineers to design and install?
Answer: Yes, we have an engineering team for ODM and OEM services
4. Question: What documents will you provide?
Answer: Usually, we provide DQ, IQ, PQ, OQ, FAT, SAT, operation manual, maintenance instructions, layout drawings, etc.
We are a manufacturer of professional designers and engineers. Our factory is located in Guangzhou city.
2. Question: How long is your warranty period? Can we expand?
Answer: 12 months after installation and debugging. The warranty can be extended at an additional charge.
3. Question: Do you have a professional team of engineers to design and install?
Answer: Yes, we have an engineering team for ODM and OEM services
4. Question: What documents will you provide?
Answer: Usually, we provide DQ, IQ, PQ, OQ, FAT, SAT, operation manual, maintenance instructions, layout drawings, etc.
