N2/H2/O2/Ar/He/NH3/CO2/Clean Dry Air/Point Of Use 7N-9N Purification Plant
Cheapest H2 Separation Units 99.99999% Continuous Gas Supply Hydrogen Purification Units for Steel Industry
Product Description
The 7N Hydrogen Purification System consists of two main parts: the gas circuit and the electronic control.
The gas circuit includes multiple parallel catalyst purification units, a series of pneumatic valves, gas pipelines, and heat
exchangers. This system uses a combination of chemical reactions and physical adsorption at room temperature to remove impurities such as H2O, O2, CO2, CO, and NMHC from the process gas, reducing them to less than 5 parts per billion (ppb). It can be equipped with particle filters with a filtration precision of 0.003 microns.
The electronic control part includes a PLC (Programmable Logic Controller), temperature controllers, and a touch screen. This part manages the purification, regeneration, and safety alarm processes, ensuring the purification system operates continuously, safely, and stably.
The gas circuit includes multiple parallel catalyst purification units, a series of pneumatic valves, gas pipelines, and heat
exchangers. This system uses a combination of chemical reactions and physical adsorption at room temperature to remove impurities such as H2O, O2, CO2, CO, and NMHC from the process gas, reducing them to less than 5 parts per billion (ppb). It can be equipped with particle filters with a filtration precision of 0.003 microns.
The electronic control part includes a PLC (Programmable Logic Controller), temperature controllers, and a touch screen. This part manages the purification, regeneration, and safety alarm processes, ensuring the purification system operates continuously, safely, and stably.
Flow Range: 10-20,000 Nm³/h
Impurity Content in Outlet Gas: Less than 5 ppb for each impurity
Particle Filter: 0.003 μm
Purification Tank: 316L Stainless Steel
Design: Multiple purification units designed for in-situ regeneration after saturation
Operation: Fully automatic operation for continuous gas supply
Impurity Content in Outlet Gas: Less than 5 ppb for each impurity
Particle Filter: 0.003 μm
Purification Tank: 316L Stainless Steel
Design: Multiple purification units designed for in-situ regeneration after saturation
Operation: Fully automatic operation for continuous gas supply
Product Model | 7N-10 | 7N-100 | 7N-3000 | 7N-10000 | |||
Purifiable Gases | H2，H2 Mixed with Inert Gases | ||||||
Standard Flow Rate | 10Nm3/h，20Nm3/h，30Nm3/h，40Nm3/h，60Nm3/h | 100Nm3/h,150Nm3/h,200Nm3/h,300Nm3/h，400Nm3/h，600Nm3/h，800Nm3/h,1000Nm3/h,1500Nm3/h,2000Nm3/h | 3000Nm3/h,4000Nm3/h,6000Nm3/h,8000Nm3/h | 10000Nm3/h,15000Nm3/h,20000Nm3/h | |||
Maximum Pressure | 1.0 | 1.0 | 1.0 | 1.0 | |||
Maximum Pressure Drop | 0.1 | 0.1 | 0.1 | 0.1 | |||
Particle Filter | 1 | 1 | N/A | N/A | |||
Removed Impurities | H2O, O2, CO2, CO,NMHC | ||||||
Purification Performance | ＜5ppb | ||||||
7N Hydrogen Purification System
9N Hydrogen Purification System
The 9N Hydrogen Purification System consists of two main parts: the gas circuit and the electronic control.
The gas circuit includes multiple parallel catalyst purification units, a series of pneumatic valves, gas pipelines, and heat
exchangers. This system uses a combination of chemical reactions and physical adsorption at room temperature to remove impurities such as H2O, O2, CO2, CO, and NMHC from the process gas, reducing them to less than 1 part per billion (ppb). It can be equipped with particle filters with a filtration precision of 0.003 microns.
The gas circuit includes multiple parallel catalyst purification units, a series of pneumatic valves, gas pipelines, and heat
exchangers. This system uses a combination of chemical reactions and physical adsorption at room temperature to remove impurities such as H2O, O2, CO2, CO, and NMHC from the process gas, reducing them to less than 1 part per billion (ppb). It can be equipped with particle filters with a filtration precision of 0.003 microns.
The electronic control part includes a PLC (Programmable Logic Controller), temperature controllers, and a touch screen. This part manages the purification, regeneration, and safety alarm processes, ensuring the purification system operates continuously, safely, and stably.
Flow Range: 10-20,000 Nm³/h
Impurity Content in Outlet Gas: Less than 1 ppb for each impurity
Particle Filter: 0.003 μm
Purification Tank: 316L Stainless Steel EP
Design: Multiple purification units designed for in-situ regeneration after saturation
Operation: Fully automatic operation for continuous gas supply
Impurity Content in Outlet Gas: Less than 1 ppb for each impurity
Particle Filter: 0.003 μm
Purification Tank: 316L Stainless Steel EP
Design: Multiple purification units designed for in-situ regeneration after saturation
Operation: Fully automatic operation for continuous gas supply
Product Model | 9N-10 | 9N-100 | 9N-3000 | 9N-10000 | |||
Purifiable Gases | H2，H2 Mixed with Inert Gases | ||||||
Standard Flow Rate | 10Nm3/h，20Nm3/h，30Nm3/h，40Nm3/h，60Nm3/h | 100Nm3/h,150Nm3/h,200Nm3/h,300Nm3/h，400Nm3/h，600Nm3/h，800Nm3/h,1000Nm3/h,1500Nm3/h,2000Nm3/h | 3000Nm3/h,4000Nm3/h,6000Nm3/h,8000Nm3/h | 10000Nm3/h,15000Nm3/h,20000Nm3/h | |||
Maximum Pressure | 1.0 | 1.0 | 1.0 | 1.0 | |||
Maximum Pressure Drop | 0.1 | 0.1 | 0.1 | 0.1 | |||
Particle Filter | 0.003 | 0.003 | N/A | N/A | |||
Removed Impurities | H2O, O2, CO2, CO,NMHC | ||||||
Purification Performance | ＜1ppb | ||||||
Detailed Photos
Product Application
Large-scale Integrated Circuit Manufacturing
Semiconductor Discrete Device Manufacturing
Large Silicon Wafer Production
Panel and Display Manufacturing
Optical Fiber Preform Production
High-efficiency Solar Cell Production
LED and Laser Diode Manufacturing
Production of Ultra High Purity Gases, Mixed Gases, and Standard Gases
Clean Pipeline Welding and Purging
Carrier and Zero Gas Purification for Analytical Instruments
Company Profile
WOBO Group has been engaged in the low-temperature and air separation industries for decades. Operating Low-temperature Application Equipment, Gas Separation Equipment, Green New Energy Equipment and other products. Providing customers with the best products and solutions has always been our goal.
WOBO Group has forged strategic partnerships with numerous renowned companies specializing in gas separation and purification, enabling us to tap into a wealth of expertise in equipment operation. Our company boasts an impeccable product development and production system, complemented by a highly skilled and experienced technical team. Our unwavering commitment lies in delivering cutting-edge products and exceptional service to our valued customers. With meticulous design, superior quality, and outstanding support, we strive to be the driving force behind our customers' continued growth and success.
