Транспортный грузовой прицеп с полным тягачом другие прицепы контейнерный транспортный поворотный
- Категории: >>>
- Поставщик: Shandong,Derun,Vehicle,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Flatbed Full Trailer | ||
Tare Weight | About 5.6-8T | |
Dimension | 11000mm*2500mm*1575mm | |
Loading Capacity (T) | ≤ 45 T | |
Axle | 13 T/16T, FUWA /BPW /DERUN | |
Rim | 9.00-22.5 | |
Tire | 12.00R22.5/ 315 80R22.5 | |
Suspension | Mechanical suspension (Germany Type or America Type) | |
Or Air suspension (China brand or BPW brand ) | ||
Spring leaf | 90(W)mm*13(Thickness)mm*10 Layer | |
Draw Bar | 4*4 or 4*6mm square tube (length is 1.4m ) | |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, | |
down plate is 16mm ; Material is Q345B Steel . | ||
Side beam | 14mm or 16mm channel steel ( Material is Q235steel ). | |
Brake chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks | |
ABS | Optional | |
Twist Locks | Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type) | |
Valve | WABCO valve | |
Light | LED light | |
Voltage | 24V | |
Receptacle | 7 ways (7 wire harness) | |
Tool box | One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) | |
Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | |
Shipping Terms: | By bulk cargo carrier, RORO or 40HQ container. | |
1. What's your MOQ?
A : One unit.
2. Do you have your own factory?
A：Yes, we have our own factory, with 18 years of experience in trailer production and sales .
A：Yes, we have our own factory, with 18 years of experience in trailer production and sales .
3. Where are you? Can I visit you?
A: Our company is located in Qingdao, Shandong province, you can contact us at any time to visit our factory.
4. How about the delivery time? How do you transport the semi trailers ?
A: Within 15-45 days after we confirm you requirement.By bulk or container. Our factory possess long -term cooperation with ship agency which can provide you the cheaper shipping fee.
5. What kind of payment does your company support?
A: T/T, 100% L/C at sight, Cash, Western Union are all accepted.Also if you have other payment terms, please contact us.
