Мини-ИБП 18 Вт 5 В 12 9 блок питания для Wi-Fi маршрутизатора модема POE 50 А ИБП источники
- Категории: >>>
- Поставщик: Foshan,Phili-Ace,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Paramenters
Model | M18P | |||||
Output power | 18W | |||||
Input characteristics | ||||||
Voltage range | 85~265VAC | |||||
Frequency range | 50Hz/ 60Hz | |||||
Surge current | ≤3A | |||||
Input fuse | 0.8A/250VAC | |||||
Output characteristics | ||||||
Port | Voltage error | Ripple voltage | Rated current | |||
USB5V | ±5% | ≤250mVp-p | 2A | |||
DC5V | 2A | |||||
DC9V | ≤680mVp-p | 1A | ||||
DCI2V | ≤900mVp-p | 1.3A | ||||
POE15V | ≤1000mVp-p | 0.6A | ||||
POE 24V | ≤1500mVp-p | 0.6A | ||||
Conversion time | 0ms | |||||
Efficiency | ||||||
Efficiency | ≥85% | |||||
Battery | ||||||
Battery | Specification | Conventional 2200mAH(1800-2600mAH can be customized) (18650 lithium battery) | ||||
Quantity | 4 | |||||
Appearance | ||||||
LED display | Power display, working status display | |||||
Dimension | ||||||
According to the normal standard configuration | Host | Dimension: L*W*H | 187*107*37(mm³) | |||
Net Weight（KG） | 0.4 | |||||
Single unit packaging | Dimension: L*W*H | 200*164*40(mm³) | ||||
Gross Weight（KG） | 0.54 | |||||
One box (20 units) | Dimension: L*W*H | 430*350*220(mm³) | ||||
Gross Weight（KG） | ≈11.6 | |||||
Operation Environment | ||||||
Operating temperature | 0°C~45°C (Typical value): 25 ℃(charging prohibited below 0℃) | |||||
Storage temperature | -10°C~70°C (Typical value):25°C | |||||
Relative humidity | (Relative humidity) 0~85 % (no condensation) | |||||
Altitude | ≤3000m | |||||
Heat dissipation method | Natural convection | |||||
