Глубокие циклы высокое напряжение 24 В 48 51 2 100Ah 200Ah 300Ah 400Ah 500Ah стеллаж солнечной энергии литиевая батарея
Глубокие циклы высокое напряжение 24 В 48 51 2 100Ah 200Ah 300Ah 400Ah 500Ah стеллаж солнечной энергии литиевая батарея
Глубокие циклы высокое напряжение 24 В 48 51 2 100Ah 200Ah 300Ah 400Ah 500Ah стеллаж солнечной энергии литиевая батарея
Глубокие циклы высокое напряжение 24 В 48 51 2 100Ah 200Ah 300Ah 400Ah 500Ah стеллаж солнечной энергии литиевая батарея
Глубокие циклы высокое напряжение 24 В 48 51 2 100Ah 200Ah 300Ah 400Ah 500Ah стеллаж солнечной энергии литиевая батарея
Глубокие циклы высокое напряжение 24 В 48 51 2 100Ah 200Ah 300Ah 400Ah 500Ah стеллаж солнечной энергии литиевая батарея
Глубокие циклы высокое напряжение 24 В 48 51 2 100Ah 200Ah 300Ah 400Ah 500Ah стеллаж солнечной энергии литиевая батарея

Глубокие циклы высокое напряжение 24 В 48 51 2 100Ah 200Ah 300Ah 400Ah 500Ah стеллаж солнечной энергии литиевая батарея


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Product Description






Model No
48100
48150
48200
51100
51200
Batteries materials
Lithium iron phosphate
Series parallel mode
15S1P
15S2P
15S1P
16S2P
16S2P
Nominal voltage
48v
48v
48v
51.2V
51.2V
Nominal capacity
100Ah
150Ah
200Ah
100Ah
200Ah
Size（mm）
465*440*195
482*590*178
500*440*260
490*440*170
670*480*350
Weight
45kg
76.5kg
80kg
50kg
85kg
Color
Optional
Parallel support
Parallel terminals are supported
Output port mode
terminal
Charging way
CC/CP/VP
Charging current
0.2C(standard）
Maximum charging current
Max0.5C @25℃
Discharge way
CC/CP/VP
Discharge current
0.5C
Charge cut-off voltage
54.75V/CELL
54.75V/CELL
58.4V/CELL
58.4V/CELL
58.4V/CELL
Maximum discharge current
Max1C @25℃
Max0.8C @25℃
Max0.6C @25℃
Max0.6C @25℃
Max0.6C @25℃
Discharge cut-off voltage
42v
42v
44.8V
44.8V
44.8V
According to
LCD
Communication interface
RS485/RS232/CAN
Charging operating temperature
charging:0~+50℃
Discharge operating temperature
discharge:-20~+55℃
Warranty
5 years
Applicable scope
hospital, bank data center, base frame type home,enterprise energy storagebackup power supply, wind complementary system,office,
military, base station and other uninterrupted energy storage power supply.


Contact us for more details

Features
- Long warranty period: 3-5 years
-Lithium iron phosphate battery
- Support parallel expansion
- Higher energy density and smaller size, suitable for home use.
- Photovoltaic system: The battery pack is designed for household photovoltaic system.
- Battery Management System (BMS): The built-in BMS monitors battery operation and prevents the battery from operating outside of design limits.
- Expandability: The battery pack can be easily expanded by adding extension cells in parallel.

SMS Energy is the right supplier for you:
We are a professional energy storage battery factory, factory headquartered in Dongguan, China, listed company, excellent enterprise in China.
Our products include 24V, 48V lithium batteries, solar inverters, solar panels, and we are contracted to design and install large-scale energy storage projects, and we have already laid a number of large-scale projects in the Middle East and Africa, including the Saudi Arabia Smart City project, and the Africa ups reserve power project.

Accept *OEM/ODM service. We can customize the products according to your requirements to ensure 100% quality to your expectation.

*Quality local after-sales service. If there is any problem with the product, we have professional after-sales technical engineers to help you solve it.

*Alibaba Gold Certified Supplier. Five-star merchant
If you are interested in our products or services, please contact us immediately! *Alibaba Gold Certified Supplier.




Product Usage





Household solar power supply system

By storing energy during the day and meeting the needs of household appliances at night, we can save your electricity costs and save energy and environmental protection;

As an emergency backup power source for households, providing power support in case of power outages or other emergency situations.


Supporting parallel connection of multiple batteries
The LiFePO4 battery is a smart battery to match all off-grid and hybrid solar inverter (48Vdc/51.2Vdc) types.

When the battery needs to be used in parallel, the maximum connection is 15 units. And we recommend 2-8 units according to application.


Why Choose Us










Cooperative Partner




Company Introduction


About Us
Shenzhen SMS Energy Storage Technology Co., Ltd. is the holding subsidiary of Zhengzhou Sanhui Electric Co., LTD. (stock code:002857). Zhengzhou Sanhui Electric Co., LTD. founded in 1996, is mainly engaged in the research and development, design,production and sales of electric energy metering instruments, and can provide standard and calibration comprehensive solutions for smart grid metering instrument users, manufacturers and verification institutions.
Now it has formed four industrial sectors:electric energy metering device, power transformer, power load management collection terminal and energy storage system. Shenzhen SMS Energy Storage Technology Co., Ltd. with 101 patents and software, is a state-level high-tech enterprise. Based on the development of smart grid construction,Shenzhen SMS Energy Storage Technology Co., Ltd.to providing intelligent automation products for customers in the power industry, with new energy power generation enterprises, power grid companies and industrial and commercial users as the main target customers.
Focusing on the research and development, production, sales and service of energy storage products on the power supply side, the power grid side and the user side, deeply involved in the development of green energy and the construction of new power systems, committed to providing customers with high-quality MW energy storage
systems, household energy storage systems and overall solutions, is a scientific and technological innovation enterprise integrating research and development, manufacturing, sales and service. Our company always adheres to the principle of "building first-class brand with strong technical strength, ensuring first-class product quality with advanced management", takes the mission of "continuously creating value for customers and providing development platform for employees", and adheres to the principle of "teamwork, honesty, innovation and service to the society". Aim, dedicated to provide our customers with the best quality service.


VR






FAQ


Q1. Are you a manufacturer?
A. Yes, sir, we have our own factory, the price is factory direct.

Q2. Can I have a sample order?
A. Yes,welcome sample order to test and check quality.

Q3. What about the lead time?
A. Sample 5-10 days, mass production time 3-5 weeks depending on order quantity.

Q4. Do you have any MOQ limit?
A. Yes, but low MOQ, 1~10pcs sample order is available.

Q5. How do you ship the goods and how long does it take to arrive?
A. We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Bigger order shipped by air or by sea.

Q6. How to proceed with an order?
A. 1st, please let us know your requirements or application. 2nd, We offer our quotation. 3rd, customer confirms the samples and make a deposit for formal order. 4th, We produce your order.

Q7. Can you print my logo on the product?
A. Yes. Please supply us the artwork before mass production.

Q8. How about after-sales service?
A. We will provide you with a 3 years warranty. If there are any problems, please let us know and we will provide you with a
positive solution.

Please feel free to contact us for Price, Packing, Shipping and Discount.
