Деловой контактор 6/932/95A 3P AC380/400 В катушка контактора механического блокировки 110

Описание и отзывы

Характеристики

Through the mechanical interlock structure, CJX2-N pull only 1 contactor,makes AC motor Reversing and Forwarding  effective.

1.Mechanical Interlock Contactor can switch on and off the circuit at a distance.

2.Mechanical Interlock Contactor using as unfrequent start,stop and reversal of AC motor.

3.Mechanical Interlock Contactor combining into the electromagnetic starter with the thermal relay.

4.Mechanical Interlock Contactor combining with the auxiliary contact block,air delayer&machine-interlocking devices.

5.Mechanical Interlock Contactor having the action structure of straight acting, contact for double breakpoints.

6.Small volume, light weight, low power consumption, long life, safe and reliable forMechanical Interlock Contactor.

7. We have Professional service before and after sale.

CJX2 CONTACTOR TECHNICAL PARAMETER:

Type		CJX2-09	CJX2-12	CJX2-16	CJX2-25	CJX2-32	CJX2-40	CJX2-50	CJX2-63	CJX2-80	CJX2-95
		(LC1-D09)	(LC1-D12)	(LC1-D16)	(LC1-D25)	(LC1-D32)	(LC1-D40)	(LC1-D50)	(LC1-D65)	(LC1-D80)	(LC1-D95)
Rated working current (A)	AC3	9	12	18	25	32	40	50	65	80	95
	AC4	3.5	5	7.7	8.5	12	18.5	24	28	37	44
AC3 capacity of phase 3 squirrel-cage motor AC3 (kw)	220/230V	2.2	3	4	5.5	7.5	11	15	18.5	22	25
	380/400V	4	5.5	7.5	11	15	18.5	22	30	37	45
	415V	4	5.5	9	11	15	22	25	37	45	45
	440V	4	5.5	9	11	15	22	30	37	45	45
	500V	5.5	7.5	10	15	18.5	22	30	37	55	55
	660/690V	5.5	7.5	10	15	18.5	30	33	37	45	45
Rated heat current (A)		20	20	32	40	50	60	80	80	125	125
Electrical life	AC3 x 106	2	2	2	2	2	2	2	1.6	1.6	1.6
Mechanical life x 106		20	20	20	20	20	20	20	20	10	10
Number of the contact		3P + NO	3P + NO	3P + NO	3P + NO	3P + NO	3P+NC+NO	3P+NC+NO	3P+NC+NO	3P+NC+NO	3P+NC+NO
		3P + NC	3P + NC	3P + NC	3P + NC	3P + NC



Q 1. what's the payment term?   ANSWER: We accept TT,30% deposit and 70% balance against copy of BL, or L/C at sight, paypal ,western union and so on.

Q 2. how's the delivery time? ANSWER: Sample within 6days ; Usually it will take about 15-25 days for production

Q 3. tell me the standard of package? ANSWER: For the small capacity, it use carton ; For big capacity, we should use strong wooden case for protection.

Q 4.Could you offer Form A ,C/O and From E ?   ANSWER: It totally not a problem. We can prepare relative documents to foreign affairs office or other office to apply for this certificate.

Q 5.Would you accept to use our logo ? ANSWER: If you have good quantity, it absolute no problem to do OEM.

Q 6.Where is your market? ANSWER: Our products are popular in Middle east , Thailand , Malaysia ,Italy, Africa ,Pakistan and so on. Some of them are our regular customers and some of them are developing. We hope you can join us and make mutual benefit from our cooperation.





 Guangxi Precision Trading Co., Ltd’s  business scope are circuit breaker Moulded case circuit breaker, contactor, Thermal relay, electrical meter, distribution box, voltage stabilizer, voltage regulator, transformer, industry plug and socket, power accessories, fuse protector and electrical products or accessories.

The best product and service is our mission , our electrical products are manufactured in strict ISO90001 production requirements and IEC international standard, and the CCC, CE, KEMA, etc famous product certification certificate.
