Б/у колесный погрузчик cat 966H на продажу 966G 966f
- Категории: Используемые погрузчики >>>
- Поставщик: H.R.,CORPORATION
Поделиться:
Описание и отзывы
Характеристики
Bucket
G
Dump Clearance At Max Raise
3086mm
Breakout Force
188kN
Bucket Width
3220mm
Bucket Capacity - Heaped
4.25m3
Bucket Capacity - Struck
3.62m3
Dimensions
E
Ground Clearance
496.83mm
A
Length With Bucket On Ground
8855mm
B
Width Over Tires
2956mm
C
Height To Top Of Cab
3600mm
D
Wheelbase
3450mm
F
Hinge Pin - Max Height
4224mm
H
Reach At Max Lift And Dump
1294mm
Height - Top Of Exhaust Pipe
3550.92mm
Centerline Of Rear Axle To Hitch
1725.17mm
Centerline Rear Axle To Edge Of Counterweight
2.46m
B-Pin Height - Standard
4.23m
Height - Top Of Hood
2679.2mm
Height - Top Of Rops
3.6m
Wheel Base
3.46m
Specifications
Engine
Number Of Cylinders
6
Engine Make
2236
Engine Model
C11 ACERT
Net Power
195kw
Gross Power
213kw
Power Measured @
1800rpm
Max Torque
1215Nm
Displacement
11.1L
Torque Measured @
1400rpm
Aspiration
Turbocharged
Torque Rise
38%
Bore
130.1mm
Stroke
140mm
Net Power - Iso 9249
195.4kw
Net Power - Sae J1349
193.2kw
Net Power - 80/1269/Eec
195.4kw
Gross Power - Sae J1995
213.3kw
Engine Model
Cat? C11 ACERT?
Flywheel Power
195.4kw
Peak Torque - 1,400 Rpm - Net
1214.9Nm
