Product Description
The SKB376 is a highly integrated BLE 4.2 module, designed for high data rate, short-range wireless communication in the 2.4GHz ISM band. The module is based on SYD8811 radio transceiver IC, which integrates a 32 bit ARM Cortex-M0 64MHz CPU, 32kB Data RAM, 512kB Flash memory and analog and digital peripherals. The SKB376 provides a low power and ultra-low cost BLE solution for wireless transmission applications.
Features
◆Main Chip: SYD8811
◆Bluetooth® 4.2 low energy
◆Support UART-to-BLE transparent transmission(Slave only).
◆Supported BLE data rates : 1 Mbps
◆RTC 4x32bit timers, RTC support
◆Quadrature decoder for HID usage
◆Cap detection for touch pad
◆ support up to 32MHz
◆10bit ADC and 6 configurable channels
◆ 19Digital I/O pins
◆SPI Master
◆Two-wire Master (I2C compatible)
◆ UART Dual UART (CTS/RTS)
◆Bluetooth® 4.2 low energy
◆Support UART-to-BLE transparent transmission(Slave only).
◆Supported BLE data rates : 1 Mbps
◆RTC 4x32bit timers, RTC support
◆Quadrature decoder for HID usage
◆Cap detection for touch pad
◆ support up to 32MHz
◆10bit ADC and 6 configurable channels
◆ 19Digital I/O pins
◆SPI Master
◆Two-wire Master (I2C compatible)
◆ UART Dual UART (CTS/RTS)
◆Support 3 kinds of Asynchronous card, compliant to ISO/IEC 7816-3: 1997
◆AES 128 HW encryption
◆ROHS compliance (Lead-free)
◆AES 128 HW encryption
◆ROHS compliance (Lead-free)
Applications
Specification
item | value |
Model Number | SKB376 |
Type | Bluetooth 4.2 |
Country of Origin | china |
Brand | SKYLAB |
Chipset | SYD8811 |
Application | Computer peripherals and I/O devices |
Model | SKB376 |
Antenna Type | PCB Antenna/ External Antenna |
Chip-set Solution | SYD8811 |
Voltage | 1.8V~3.6V |
Wireless Standards | Bluetooth 4.2 |
Frequency Range | 2400MHz---2483.5MHz |
Data Rates | 1Mbps(Bluetooth 4.2) |
Wireless Security | AES HW Encryption |
Transmit Power | Tx Power -20 to +4 dBm in 2 dB Steps |
Work Mode | Peripheral (Slave device in BLE connection) |
