Стандартный Композитный падение-предохранитель силастика для высокого


Поделиться:

Цена:371,64 ₽ - 7 432,71 ₽*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики


Product Description

Standard composite drop-out fuse for high voltage




Main parameters:

Item

Unit

Data

Rated Voltage

kV

12

Rated Current

A

100/200

Rated Frequency

Hz

50/60

Rated Fuse Base Current

A

100/200

Rated Short-circuit Breaking Current

kA

12.5kA, 16kA

(4time for 100A, 1time for 200A)

Rated Power Frequency Withstand Voltage (dry/wet)

kV

60/50

Rated Lightning Impulse Withstand Voltage(phase to earth/across the isolating distance)

kV

125/150

Creepage-distance

Porcelain

mm

372



Composite polymer



480

Mechanical Life

Unload Type

times

2000(continuous switch on- off)



Load Type



500(continuous switch on- off)

Elevation

m

2000

Ambient Temperature

°C

-40 ~ +70




Technical Data





RELATED PRODUCTS


COMPANY INFORMATION

.jpg

CERTIFICATION


PACKING & DELIVERY


CONTACT US


FAQ




1.Q:Are u the factory or trading company?

A: We are factory who was founded in 1996



2.Q:What's your main products?
A: insulators, hardware of all kinds for high-voltage applications and related products.



3. Q: Can I get some samples?
A: Yes, sample order is available for quality check and market test.



4. Q: What’s your payment terms?
A: We usually accept all kinds of payment terms, T/T, L/C, Western union, Cash.



5. Q:How can you control your quality?
A:For each production processing, we have complete QC system for the chemical composition, physical and electrical properties. After production, all the goods will be tested according to related standards, and the ex-factory test reports will be sent along with shipment documents.



6. Q:Does your company accept customization?
A:We accept OEM service.



7. Q: What’s your warranty terms?
A: We offer 24 months warranty terms.



8 Q: Do you have the products in stock?
A: Depends on your request,we have standard models in stock.Some special product and big order will be newly produced according to your order.



9 Q: What do you have for certificate?
A: ISO9001, ISO14001, Type test, CESI etc.



10 Q: How to become the agents for TCI?
A: We welcome you to be TCIs agent.

We will depend on the sales turn over and also do research on your market. If your have interest, let us discuss more !



11.Q:Can we visit your company?
A:Yes, for sure, you are welcome to visit our company.
