Латунный отводящий клапан 1 дюйм для солнечного нагревателя Селекторный

 BXHX25 --- DIVERTING VALVE SELECTOR VALVE

  BXHX20 --- 1" Diverting Valve

1. Technical Data

BXHX20  G1”

a. Maximum working temperature: 99 C

b. Rated outlet flow on 1 bar pressure drop:38.3L/Min

2. Materials of Construction

a. Valve body: Nickel plated brass

b. Shutter: PPO

c. Connection: Inlets-M, outlet-M

3. Usage of Selector valves

Point of use mixing for wash hand basins, bidets, baths and showers in hospitals, schools, sport and leisure facilities, prisons and other public buildings.

4.How they work ?

Temperature range: 40---45℃

When coming water is below 40℃, it will flow out from cold port. When above 45℃, flow from hot port. When the temperature between 40—45℃, it will flow from both ports.

Normally it is applied in solar heater and gas/electric water heater system. When sun shine is short and water temp from solar geyser is not hot enough, the water will be flow into for the secondary heating, such as gas or electric heater for second heating.

For detailed information, please see the below picture:

• What is the constant temperature?
Constant temperature is a constant temperature in a certain environment. Precise instruments are needed to measure the change of temperature at any time, and then adjust the temperature to make it always a temperature.

• Thermostatic mixing valve?
Thermostatic valve is a warm system supporting products, widely used in electric water heater, solar water heater and heating water system. And the application in electric water heaters and solar water heaters, can automatically adjust the temperature according to the need of cold and hot water mixing, the required temperature can be achieved quickly and stable, ensure the water temperature constant, and is not affected by water temperature, flow, pressure changes, wash bath center solve problems when the cold water temperature sometimes hot and sometimes cold, interrupt hot water, water mixing valve can be automatically closed in a few seconds, play a security role.

• Thermostatic valve choice?
The different applicability of different thermostat valves
Commercial large flow constant temperature valve: suitable for children's swimming pool, school, hospital, senior club, beauty salon center, bath center and other places.
Common constant temperature valve: suitable for household use, can be used with water heater and water faucet, can be used with bathtub faucet and shower screen.
Solar special thermostat valve: because of its cold and hot water pressure adjustable, especially suitable for solar water heater.
