2 seats electric golf buggy for sale (LT-A2.H8)
Product Description
Electric system | controller | 1268/400A | |||
battery | Trojan battery 8V,6 units | ||||
motor | KDS48V/3.7KW motor | ||||
charger | Computer Intelligent,input 220V/110V,ourput 48V,20A | ||||
Charging time | Less than 12 hours(discharging rate 80%) | ||||
Body configuration | Glass | PC glass | Sun Roof | ABS Vacuum forming
| |
seat | leather | Floor | Autiskid rubber floor | ||
Rear mirror | Handoperated,both side | Steering | Dual automotive-style strut and self-adjust rack-and pinion steering | ||
DC/Light/Signal | 48V/12V-300W Front light,turning light,rear light,horn,Buzzer | ||||
Body | PP Vacuum forming | ||||
Dash Board | PP Vacuum forming,Voltage Indicator 48V,Switch Head Lights,Switch - Indicators Right/Left,key switch,Switch - Forward/Reverse. | ||||
Braking system | Rear drum brake+compound pedal brake | ||||
Front axle and suspension | Independent suspension,helical spring +cylinder hydraulic shock absorption | ||||
Rear axle and suspension | Integral type transaxle,gear ratio 12.31:1,semi-independent transaxle,spring,cylinder hydraulic shock absorption | ||||
Tire diameter | 452mm | ||||
Parameter | Length*width*height | 3600*1200*1900mm | |||
Container sixe | 1840*1086*265mm | ||||
Loading passenger | 2 | ||||
Max speed km/h | 22km/h | ||||
Mileage /km | 70—90km(flat road) | ||||
Container truck (KG) | 300KG | ||||
Max climbing ability | 25% | ||||
Mini turning radium(m) | 5.4m | ||||
Mini ground clearance | 110mm | ||||
Wheel base | Front 930/back 1010mm | ||||
Braking distance | 5.5m | ||||
Packaging & Shipping
1.Delivery date: 15 days for mass producing
2. 1*20'GP fit 4 units.1*40'HQ fit 16 units.
3. Asia: 3-7 days to arrive; Other : 15-30 days to arrive.
Our Services
Payment:
1. T/T
2. L/C
Color of choice:
CE Certificate & ISO9001:
Company Information
1). 13 years experience in Producing the golf cart and golf cart parts.
2). America Curtis programmable controller.
3). 11 years Alibaba gold supplier.
4). 5 stars supplier of Global Sources.
5). North America ,European, Australia and Asia are the main market.
