Высокомощный блок питания 12 В 24 1500 Вт 1800 48 постоянного тока выходной источник 30 60
Высокомощный блок питания 12 В 24 1500 Вт 1800 48 постоянного тока выходной источник 30 60
Высокомощный блок питания 12 В 24 1500 Вт 1800 48 постоянного тока выходной источник 30 60
Высокомощный блок питания 12 В 24 1500 Вт 1800 48 постоянного тока выходной источник 30 60
Высокомощный блок питания 12 В 24 1500 Вт 1800 48 постоянного тока выходной источник 30 60
Высокомощный блок питания 12 В 24 1500 Вт 1800 48 постоянного тока выходной источник 30 60
Высокомощный блок питания 12 В 24 1500 Вт 1800 48 постоянного тока выходной источник 30 60

Высокомощный блок питания 12 В 24 1500 Вт 1800 48 постоянного тока выходной источник 30 60


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Product Description




Specification


Model
SCN-1500-12
SCN-1500-24
SCN-1500-27
SCN-1500-48
DC Voltage
12V
24V
27V
48V
Rated Current
125A
100A
62.5A
32A
Current Range
0-125A
0-100A
0-62.5A
0-32A
Rated Power
1500W
1500W
1500W
1536W
Ripple & Noise
120mVp-p
150mVp-p
240mVp-p
480mVp-p
Voltage Adj. Range
10.8~13.2V
20~26.4V
24~30V
41~56V
Voltage Tolerance
±5%
±5%
±5%
±5%
Inlet Stability
±1%
±1%
±1%
±0.5%
Load Stability
±1%
±1%
±1%
±0.5%
Setup, Rise, Hold Up Time
800ms, 50ms, 16ms at full load
Voltage Range
200~260 VAC47~63 Hz;290~370VDC
AC Current
12A/230VAC
Efficiency
83%
84%
85%
87%
Inrush Current
120A/230V
Leakage Current
<3.5mA/240VAC
Over Load
110%~135% Type: plusing hiccup shutdown Reset:auto recovery
Over Temp.
RTH>=80 output shutdown
Working Temp., Humidity
-10℃~+60℃(Refer to output derating curve),20%~90%RH
Storage Temp., Humidity
-20℃~+85℃, 10%~95%RH
Temp. Coefficient
±0.03%/℃(0~50℃)
Vibration
10~500Hz,2G 10min,/1cycle,Period for 60min,Each X.Y.X axes
Withstand Voltage
I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
Isolation Resistance
I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC
Safety Standard
Design refer to UL1950,CSA22.2,IEC60950
EMC Standard
Design refer to FCC Part 15 Class A
OTHERS
Dimension
291*132*132mm(L*W*H)
Weight
5.0Kg


Details Images
