                Thermal Ctp plate developer & replenisher



For developing Conqueror®, Ipagsa®, Kodak®, Konica®, and Southern thermal laser and positive plate systems.

For use in any positive plate or positive thermal plate processor.

Finish with PreBake if baking.  Finish with Subtractive Finisher if not baking.

Package: 20L Read-to-use



Plate Type: IR-sensitive, Positive, Thermal CTP Plate

Developer: Culmination DV-6

 * Ready-to-Use 20Lt. Bottle

Developer bath life:10days or 2,000m2

Image reproduction: Good

Laser characteristics:Thermal830nm

Replenisher: Culmination DVR-6

* 20 Liter Ready-to-Use

Replenishment rate: From 110ml/m2-130ml/m2 whilst processing, 60-65ml/hour whilst standing. 40-45ml/hour when machine stop work.

Resolution: 250lpi (1-99%)

Run length (baked): 1,000,000

Run length (unbaked): 150,000

Safelight environment: yellow light 10 min.;

Sensitivity:130-175mJ/cm2

Exposure density: (ptr8000) 75%, speed 750r/min

Storage: 12 months @ 25 degrees Celsius

Working conditions 21oC to 25oC; temperature change +/-1oC within the mentioned range. Humidity 50% - 60% (non condensing), change<5% per hour

UV-ink characteristics (baked): Good

UV-ink characteristics (unbaked):100,000



Process: (Grafmac W-PTP32CDN Processor)

Room temperature: 28 C

Developer PHscale : 12.0-13.0

Developer Electrical conductivity: 84-90us/cm

Develop time: 25 +/_ 3 s

Develop temperature: 25°C

Use original liquid both, no water adding.

1^st developer only pour to tank of processor, replenisher will be adding automatically through the pipe , when the developer concentration is getting weak.

Bake temperature: ………………320°C

Bake time: 5 min. or more



Room Temperature	28C
Develop Ph Scale	12.0-13.0
Develop Electrical Conductivity	84-90us/cm
Develop Time	25 +/_ 3 s
