MUP-C746 SMT sim card socket reader holder 8+8Pin for Mobile pos HOT
- Категории: Sockets for ICs >>>
- Поставщик: Shenzhen,Mup,Industrial,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Mobile card holder
Technical characteristics
1.General characteristics
Dimensions:17.10L*16.80W*3.70H mm
Weight:0.45g
Contact principle:Friction technology
Operating position:shaft up/down/horizontal
Mounting system:SMT(post optional)
Durability:1500 cycles min
2.Mechanical characteristics
Insulation material:Thermoplastic
3.Electrical characteristics
Number of contacts(optional:6pins
Contact resistance:50MΩ typical,1000 MΩ max
Insulation resistance:>1000 MΩ/500V DC
4.Solderability
Wave:not applicable
Vaporphase:215oC,30sec Max
IR reflow:230oC,15sec Max
Manual soldering:not applicable
5.Environmental characteristics
Operating temperature:-25oC≈ +70oC
Operating humidity:10%≈+95%RH
temperature:-40oC≈+85oC
Storage humidity:10%≈+95%RH
Thermal shock: -40oC+85oC,5cycles
Damp Heat:40oC,90%RH,10days
Salt-mist:35oC,5%Nacl,24H
\\\\
\\\\
Company profile
Manufacturing Line
Product Application
Certification &Exhibition
Delivery
Service
| Price Term | ♦ FOB Shenzhen EXW |
| Payment Terms | ♦ T/T, Paypal |
| Delivery | ♦ UPS, DHL, FEDEX,TNT |
| ♦ Select the most economic and efficient way. | |
| ♦ Sent the tracking number to u after delivery. | |
| Samples | ♦ Free samples will be sent on request. |
| ♦ The samples lead time is within 3-5 days after u confirmed. |
Why choosing us:
1. Almost 20 years of R&D and manufacturing experience in the connector industry.
2. A variety of channels to satisfy various demands including industrial product.
3. Sufficient stock for your urgent demand.
4. Professional high quality service to solve your confusion.
5. Timely reply within 2 hours during working time.
Who we are:
1. Shenzhen MUP INDUSTRIAL CO.,LTD is a reliable and professional connector supplier.
2. We can be No.one in this field.
3. We are with great passion of it.
4. We know, we can gain what we seed.
5. We can surpass our competitors by achieving it.
6. Our customers will trust us and make long-term cooperation with us.
7. Enterprise spirit : Honest &Trustworthy Enterprising Win& win
What we do :
MUP has a number of highly experienced , passion and dedicated professional R & D team, Produce various precision connectors with stable quality , Products widely used in Banking Equipment, Computer Communication, Advertising Machine, Automotive Electronics, Smart Reader, Smart Watch, STB: MUP has established a long-term stable cooperative relations with many well-known enterprises domestic and overseas. To be your reliable and convenient purchasing partner and become the most trusted brand in the industry is our goal.
