Filter Bag Making PP Fabric Sealing Hot Air Welding Machine achieves seam sealing in forming tube of making filtration bag manually, this filter bag hot air welding machine is designed to be precise and continuous for increased output of top quality filter application, by using hot air welding, the user can accomplish the seam sealing in overlap of two fabric layers made of PTFE,PP,Non-woven,PE,PA together without the use of tape or bonding chemical, which adopts the principles of heat, speed and pressure to get the perfect welded seam, this workable solution you chose will depends solely upon your specific needs
Hot air welding machine for filter bag | |
Mainly application | |
Filter Bag Making PP Fabric Sealing Hot Air Welding Machine Applied for welding the filter bag side by hot air under suitable pressure, the machine is electric heating method and transfer heat to the jointing interface, when the material reach its melting point, under the top and bottom rollers generate the suitable pressure, the overlap or laminated fabric is melting together, at the same time, the traction rollers produce a forwarding force to drive the finished filter bag output in side direction Filter Bag Making PP Fabric Sealing Hot Air Welding Machine is mainly used for filter bag welding, through the replacement of mold can also be applied lace clothes, bed sets, pillow cases, car kits, tents, packing tape, backpacks, travel belt, hand strap, curtains, raincoats , coat, snow suits, toys, gloves, tablecloths, chair covers, quilt, masks, hair ornaments, jewelry, umbrellas, lampshades welding | |
Mainly parameter | |
Name | Filter Bag Making PP Fabric Sealing Hot Air Welding Machine |
Model | KL-120 |
Temperature | 30~600 degree |
application | PE,PP and PPS |
Thickness of material | 0.5 to 2mm |
Maximum heating speed | 7-14meters/minute |
Sealing width | 12mm,14mm,16mm,18mm,20mm,22mm |
Diameter of filter bag | 12 to 400mm |
Overall dimension | 1.1*1*1.5m |
Net weight | 200 KG |
Motion control | Motor speed drive |
Frequency | 220V Single phase |
Working pressure | 0-5 kg |
Maximum output power | 1200W |
Character | |
01: Adjustable temperature, width, speed and roll prussure to fit different size material. 04: Adopt the steelwork and sliding guide rail struction 05: the operation panel has power switch, temp display, control and speed control 06: the heating temp is auto compensation and current temp is displayed 07: the machine is easy operation, compacted design and high efficiency | |
Notice | |
MFR: KEEPLEADERTM has modified and designed Filter Bag Making PP Fabric Sealing Hot Air Welding Machine to accommodate our customers’ unique and special requirements, pls contact KEEPLEADERTM for tech assessment |
Filter Bag Making PP Fabric Sealing Hot Air Welding Machine is our semi-automatic hot air welder in filter bag making, which also has optional construction with auto feeding stand, the fabric will be automatic feed in roll, manual model is also arranged for flexible production, the autoamtic model can improve the productivity, depends on your actually production, you can select your favored solution
After purchasing at KEEPLEADER™ is first step of our after-service, all of machines at KEEPLEADER™ has one year guarantee, we provide free samples for defected parts to do replacement except for human damage, under information for your notice
01: KEEPLEADER™ always posts the new technical file in our homepage that can help our client in new technical information of machines’ design, character, application, operation, maintenance,
and related, KEEPLEADER™ also welcome our clients feed back the machines’ working condition that can get one to one service
02: If the machine you purchased has any defects, please contact sales representative at KEEPLEADER™, we will assign our experienced engineer analyze your case and provide technical support, in case of damaged parts that cannot repair, KEEPLEADER™ will provide a new parts to replace the defect
03: For any replacement and maintenance, KEEPLEADER™ has user manual and training video
04: KEEPLEADER™ can go to oversea for on-site training
05: KEEPLEADER™ can provide electric diagram if in need
Filter Bag Making PP Fabric Sealing Hot Air Welding Machine acts as ancillary seam sealing device in filtration filter making, which perform better in forming the tube,sleeve, electric heated air to apply high pressure hot air under holding pressure at the two or three layers of overlapped fabric, the blew area under controllable pressure melt and bond together instantly, because of all of welding parameter involved are preset at its prominent scale, the temperature won’t exceed the melting point in resulting of burning happen
How can I buy good quality Filter Bag Making PP Fabric Sealing Hot Air Welding Machine
Firstly: with on line or email conversation, to check the supplier is professional or not, if the supplier has ever supplied the similar machines to other buyer, will be better, don’t save time on studying, don’t stop asking questions before order, more time and efforts you spend, more you can get on the purchasing
What is the auxiliary equipment for Filter Bag Making PP Fabric Sealing Hot Air Welding Machine?
It need one air compressor and necessary tooling, KEEPLEADER ™ can also make the tooling according to your welding products, the buyer need to provide samples and 3D drawing
I never use Filter Bag Making PP Fabric Sealing Hot Air Welding Machine before, how can I operate it?
For small machine, under 10kw, it is easy, KEEPLEADER ™ will provide user manual and train video, also have on line service to resolve any problem
For big machine, example: 50~100kw, Engineers of KEEPLEADER ™ will come to your country, help to install the machine, and train your workers. Buyer also can come to China 1~2 days for necessary Factory training before shipment
Does KEEPLEADER also makes the tooling?
Yes, KEEPLEADER ™ has tooling department, can do customized, please provide samples and 3D drawing of igs format after order
What information does buyer need to provide in advance?
Please let KEEPLEADER ™ know, 1: material, 2: thickness, 3: size of your products, 4: sample picture, 5: purchasing budget
Does KEEPLEADER has messenger for on line service
Skype: keepleader
Whatsapp:+86 13590415784
How long is the warranty time?
One year
Filter Bag Making PP Fabric Sealing Hot Air Welding Machine is the basic model of hot air welder in filter bag makings, keepleader, we tailor solution in plastic bonding process, our service team is dedicated to keeping our customers’ business running at optimal performance and assiting with any solutions they need, we are standing by to help you, let’s know more upon your bonding object for tech verification to accomplish validated sample prior to order
