Small Clinical Centrifuge TD4
Features
1. Full metal housing
2. Stainless steel chamber
3. Microprocessor cotrolled
4. Maintenance-free, quiet, and DC brushless motor
5. Air cooling
6. Digital display of speed and time
7. Control of speed and time
8. Set conditions can be changed while spinning
9. Interlocking door for safety
10. Display of abnormality: imbalance, over-speed, door-open, motor failure, communication failure and system failure
Specifications
Model |
TD4 |
Maximum RPM |
4000r/min |
Maximum RCF |
2200 x g |
Maximum Capacity |
180ml |
Temperature Range |
Air cooling |
Timer |
99 min |
Speed Accuracy |
±50r/min |
Noice |
≤65dB |
Digital Display |
RPM and Time |
Drive Motor |
DC Induction motion |
Dimension (W x D x H) |
400x 340 x 270 mm |
Weight |
16 kg |
Power Requirements |
AC 220V, 50 Hz, 3A |
Rotors
Rotor Type |
No. |
Capacity |
Max Speed (r/min) |
Max RCF(×g) |
Material |
Fixed Angle Rotor |
|
12x 10ml |
4000 |
2200 |
Plastic |
Fixed Angle Rotor |
|
12x 15ml |
4000 |
2200 |
Plastic |
Fixed Angle Rotor |
|
12x 20ml |
4000 |
2200 |
Plastic |
Fixed Angle Rotor |
|
18x 10ml |
4000 |
2200 |
Plastic |
