Durable floating carriage micrometer

at reasonable prices

ZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZZ



Even the person who was inexperienced in operation with one hand attached

a constant pressure device to get rid of unevenness and the individual difference

of measurements and enabled the stable measurement.



Outside Micrometers

SERIES 103

1. Baked-enamel-finished frame.

2. Measuring faces: Carbide

3. Equipped with Ratchet Stop for constant measuring force.







Order NO.	Brand name	Range	Graduation	L	a	b	c
103-137	M110-25	0~25	0.01	30.3	2.8	9	28
103-138	M110-50	25~50	0.01	55.3	2.8	10	38
103-139	OM-75	50~75	0.01	80.3	2.8	12	49
103-140	OM-100	75~100	0.01	105.3	2.8	14	60
103-141	OM-125	100~125	0.01	132.8	5.3	17	79
103-142	OM-150	125~150	0.01	158.2	5.7	19	94
103-143	OM-175	150~175	0.01	183.6	6.1	20	106
103-144	OM-200	175~200	0.01	208.8	6.3	19	118
103-145	OM-225	200~225	0.01	234.2	6.7	18	130
103-146	OM-250	225~250	0.01	258	5.5	18	143
103-147	OM-275	250~275	0.01	284	6.5	18	156
103-148	OM-300	275~300	0.01	309	6.5	18	169



Technical Data

Flatness: 0.6μm/.000024"for models up to 300mm/12"

1μm/.00004" for models over 300mm/12"

Parallelism:

(2 + R/100) μm, R = max, range (mm)

[.00008+.00004 (R/4)]", R = max, range (inch)

*fraction rounded dow
