Лучшее качество 150 Вт IP67 Светодиодный драйвер для уличного освещения 4
- Категории: Светодиодный драйвер >>>
- Поставщик: ANTRON,ELECTRONICS,CO.,LTD.
Поделиться:
Описание и отзывы
Характеристики
Product Series
Electrical Ballast
Antron has established reputation in fluorescent ballasts in the market on T5, T8, T10, T12, CFL, Biax PLL and UV lamp ballasts. Our ballast meet UL, CE, FCC and RoHs regulations.
LED Driver
Antron developed, manufactured and customized LED drivers that were highly valued by worldwide customers. Our driver meet UL, CE, CEC, FCC and RoHs regulations.
Product Features
- Universal input voltage 120-277, 347 and 347-480 Vac
- PFC and isolated design
- High efficiency up to 90%
- 3-in-1 dimming (PWM/1-10V/Resistor)
- Open/Short/Over-Voltage/Over-Temperature protection
- IP67 waterproof form factor
- Suitable for UL dry and damp location
- Economic and reliable power solution
- 5 years warranty
Electrical Spec
Model Series | WAT-150W | ||
AC Input | Input Voltage | 120-277 Vac 347 Vac 347-480 Vac | |
Input Frequency | 60Hz | ||
Leakage Current | <0.75mA | ||
Turn On Time | <1s | ||
Inrush Current | <50A | ||
Power Factor | >0.9 | ||
THD | <20% | ||
DC Output | Output Current | 0.7A 1.05A 1.3A 1.5A 1.8A 2.1A 2.5A 2.8A 3A 3.5A 4.2A | |
Output Voltage | 128-214V 86-143V 69-115V 64-107V 60-100V 50-83V 43-71V 36-60V 32-54V 30-50V 26-43V 22-36V | ||
Output Power | 150W | ||
Output Current Tolerance | ±5% | ||
Output Current Ripple | <10% | ||
Efficiency @Highest Vin | 90% | ||
Protection | Short Circuit | Hiccup mode, recovers automatically after fault condition is removed. | |
Over-Voltage | Output current decade mode, recovers automatically after fault condition is removed. | ||
Over-Temperature | Shut down o/p voltage, re-power on to recover. | ||
Surge | 4kV | ||
Environment | Operation Temperature | Tcase -40°C~90°C | |
Storage Temperature | Tcase -40°C~90°C | ||
Humidity | 10%~90% | ||
Safety | Safety Approval | UL8750 UL1310 | |
UL/cUL Class 2 | V | ||
UL/cUL Class P | V | ||
Withstand Voltage | I/P-O/P: 2.0K Vac, I/P-FG: 2.0K Vac, O/P-FG: 0.5K Vac | ||
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG:100Mohm/500VD | ||
Noise | Sound Rating Class A | ||
EMC | EMI | FCC Part 15 class A, UL8750, CSA C22.2 No. 250.13-14, ICES-005 Issue 4 | |
EMS | FCC Part 15 class A, UL 8750, ICES-005 Issue 4 | ||
Model Series | Case Code | L | W | H | Unit |
WAT-150W | AM168 | 241 | 68 | 40.5 | mm |
Packing & Delivery
Packing Information
10-20 pieces per carton.
Individual packing is optional.
Our Company
Our Service
Excellent Quality
Our LED drivers and ballasts are highly reliable with overall return rate below 0.3%. Antron promise we can return two placements for one fail with the new order. We are confident our products is reliable and you can enjoy the high quality of powered by Antron.
Note:
1. The policy is exclusive for Alibaba customers.
2. OEM/ODM is not applicable.
Note:
1. The policy is exclusive for Alibaba customers.
2. OEM/ODM is not applicable.
Experienced R&D and QC System
Founded in 1984, Antron has established reputation in fluorescent ballasts and continuously dedicated to be the leading expert in LED drivers globally. With more than 30 years of experience in lighting power supply, Antron developed, manufactured and customized LED drivers, fluorescent ballasts and emergency LED drivers that were highly valued by worldwide customers.
Product Warranty and Liability
To start with, Antron has more than 30 years of experience in the lighting industry. Most of our competitors only accept mass order rather than low-volume orders. But to us, any amount of order is great order. We do not discriminate. We are proud of our top-quality product, most of our products also have 5 years warranty. Besides, we have $5 millions product liability insurance that secures our clients’ rights and interests.
We can do more.
In addition to our current products, Antron specializes in adapting our products to meet individual specifications that represented by the rapid mass market. If our existing products assortment does not meet your exact needs, we can quickly and economically modify, adapt and design.
Certifications
FAQ
Why should I choose Antron?
We are a professional LED driver manufacturer with more than 32 years experience. We have an experienced R&D team, high-quality production line, mature QC control process. Quality, Service and Innovation are the core value of Antron.
We are actively looking for long term partner and welcome you to join us.
What is your minimum order quantity (MOQ)?
There is no minimum order restriction.
What is your lead time?
The delivery time will be 1~45 days depends on the product and quantity.
Can we be your distributor?
We are very welcome you can become our family.
Can you provide OEM/ODM service?
OEM and ODM are welcome.
We have a strong R&D team can quickly design and modify what you need.
