Блок питания для промышленного сварочного аппарата 400 А
Блок питания для промышленного сварочного аппарата 400 А

Блок питания для промышленного сварочного аппарата 400 А


Поделиться:

Цена:395,00 $ - 400,00 $*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики


Product Description
Features
1. Double IGBT Module technology and PWM control, high quality and superior performances.
2. Digital display, accurate current control, stable arc transition and excellent welding chaaracteristics.
3. Adjustable wire feeding speed, tip ball removing and electronic induction regulating.
4. Effective spatter control, improved penetration and better welding effect. Thermal overload protection.
5. Separated welder and the wire feeder; suitable for welding at high places or special position.
6. Wide range of working material, such as low carbon steel, low alloy steel, etc.
Technical Specifications
ITEM
UNIT
MIG-280
MIG-350
MIG-500
Input Power Voltage
V
AC380V±10%
AC380V±10%
AC380V±10%
Input Power Frequency
Hz
50/60
50/60
50/60
Rated Input Capacity
KVA
9.4
14
25
Output Current Range
A
50-270
50-350
50-500
Load Voltage
V
16.5-27.5
16.5-31.5
16.5-39
Rated Duty Cycle
%
60
60
60
Wire Feed Speed
M/min
3-15
3-15
3-15
Gas Flow
L/min
15-20
15-20
15-20
Dimensions
MM
500*235*400
500*235*400
550*270*450
weight
Kg
18
20
25
Related products
Company Introduction
Certifications
Exhibition
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.

b. We use all new components,mosfet tube, diode, capacitor and so on imported components.

c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.

d. We provide Warranty period of 1 year for all our items
