TM30A-A диафрагменный вакуумный насос 12 В/Вакуумный постоянного тока/вакуумный 24
- Категории: >>>
- Поставщик: Changsha,TOPS,Industry,And,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
TM30A-A Diaphragm 12V Vacuum Pump/DC Vacuum Pump/24V Vacuum Pump factory
Remarks:
- We are high-end micro DC pumps manufacturer. Can provide customized services
- If you are interested in our products, pls feel free to contact us
Product Description
Product Specification
| Model | TM30A-A | TM30A-B | TM30A-C | TM30A-D |
| Motor type | A--high performance Brush motor | B--Brush motor | C--Brushless motor | D--Brushless motor |
| Pump Assembly Rated Life | 3000hour | 1000hour | 15000hour | 15000hour |
| Gas flow | 6L/min | 4.5L/min | 4.5L/min | 4L/min |
| Rated Voltage | 12V | 6/12/24v | 6/12/24v | 6/12/24v |
| No-load Current | 0.24A | 0.4/0.24/0.15A | ||
| Media | Most gas | |||
| Max Pressure | 120kpa | |||
| Max Vacuum | -70kpa | |||
| Ambient Temperature | 41 to 158 F(5 to 70C) | |||
| Pump size | 75.5*30.4*54.6mm | 75*31.2*57.5mm | 79*31.2*57.5mm | 79*31.2*57.5mm |
| Weight | 200g | 150g | 250g | 250g |
| Inlet&Outlet | OD 4.8mm/ID 2.6mm,hose suggestion:ID 4.0mm | |||
| Materials | pump head Nylon, membrane EPDM , valve EPDM | pump head Nylon, membrane EPDM / PTFE, valve EPDM / FPM | pump head Nylon, membrane EPDM / PTFE, valve EPDM / FPM | pump head Nylon, membrane EPDM / PTFE, valve EPDM / FPM |
Wetted material options | 1.Optional membrane materials: EPDM for normal air PTFE for corrosive air,like acid, alkali air, ozone etc. 2.Optional valve materials: EPDM for normal air FPM for corrosive air, like acid, alkali, ozone,etc. | |||
TOPSFLO Diaphragm series gas pumps are the perfect combination of form and function. The use of a special diaphragm allows the pump to transfer both air and liquid efficiently. The compact lightweight unit offers optimum sizing for analytical equipment.
ADVANTAGES
♦ High pneumatic performance
♦ Compact size/high power density
♦ Uncontaminated flow – no contamination of the media due to oil-free operation
♦ Maintenance-free
♦ Long product life
♦ Low sound level
♦ Low power consumption
♦ Can operate in any orientation
♦ Suction
APPLICATION
1. Industrial pressure and vacuum applications 2. Portable Analytical Instruments 3. Medical Diagnostic Equipment
4. Air Quality Sampling Monitors 5. Respiration Monitors 6. Gas or Odor Leak Detectors etc..
4. Air Quality Sampling Monitors 5. Respiration Monitors 6. Gas or Odor Leak Detectors etc..
Performance Curve
Company Information
You want it, We all have !
APPLICATION FIELD
Trustworthy micro pump supplier
Typical Applications:
>>Vacuum packaging Vacuum preservation
>>Industrial pressure and vacuum applications
>>Portable Analytical Instruments
>>Medical Diagnostic Equipment
>>Air Quality Sampling Monitors
>>Respiration Monitors
>>Industrial pressure and vacuum applications
>>Portable Analytical Instruments
>>Medical Diagnostic Equipment
>>Air Quality Sampling Monitors
>>Respiration Monitors
>>Beauty equipment
>>Gas or Odor Leak Detectors
>>Gas or Odor Leak Detectors
If you don’t have one of your application areas, please contact us!
