Product Description
Data sheets:
| Item | Specification | |
Technical Key Specifications | Printhead | Double 5113 Printheads |
| Noozle configuration | 180 nozzles × 8 lines / head (K/K/C/C/Y/Y) | |
| Ink-supply systerm | Continuous large capacity for ink system, standby application ink: 1000ML/color | |
| Drop Mass range (pl) | 3.5-21 | |
| Media thickness | 2-4mm | |
| Resolution | 360×720dpi, 720×720dpi, 720×1440dpi | |
| Max. Reel diameter | 350mm (max 80kg reel) | |
| Medium processing | Max Printing size | 180cm |
| Paper feed system | Standard automatic paper feed system | |
| Competible print media | Lamp piece PP Heat transfer paper, glass, textile fabric etc | |
| Ink type | Dye sublimation, Pigment, Photo-Dye, Eco Solvent | |
| Ink Cartridge Capacity | 220ml cartridge + CISS System 1000ml (1 litre) | |
| Drying system | Hot drying or Cold drying can be choose | |
| Machine configuration | Interface | High-Speed USB 3.5 Interface |
 | ||
| Item | Specification | |
| Others | RMA | Competible PC 128M or 256M |
| Power Consumption | Standby is 24V ,general is 400W | |
| Operation envirement | The relative temperature, noncondensable 18 °C~30 °C( 65OF ~ 86OF ) 20%~70% | |
| Driving System | Windows XP | |
| Software | Main Top Or Wasatch | |
| Disposer | 32 bit RM | |
| Power | 220V AC,50HZ (voltage can also do 220v,60hz,2phase,it can do according to your request) | |
| Noise | Standby:< 30 DBA working:< 58 DBA | |
| Storage envirement | The relative temperature, noncondensable -20 °C~60 °C(-5OF ~ 140OF ),5% ~ 80% | |
| Language | English,Chinese | |
| Size | Certification | CE |
| Machine size | 2800*1300*800mm | |
| Package size with wooden | 310×85×74cm | |
| Weight | N.W.180kg G.W.250kg | |
| Print speed | Production model 2pass :360*360 dpi | 80.0 M2/Hour |
| 3pass :360*720 dpi | 60.0 M2/Hour | |
| 4pass :720*720 dpi | 45.0 M2/Hour | |
After-Sale Service:
1. Long life services, save your cost.
2. One year warranty for one machines.
3. Best technical support- avoid problems during production.
4. If you meet problems, we can offer:
5. User Manual in English.
6. Operation Video.
7. Technical Support on-line.
8. You can dispatch your technician to our factory to attend the skill training.
9. If you still can not solve the problems, we can provide door to door services,
2. One year warranty for one machines.
3. Best technical support- avoid problems during production.
4. If you meet problems, we can offer:
5. User Manual in English.
6. Operation Video.
7. Technical Support on-line.
8. You can dispatch your technician to our factory to attend the skill training.
9. If you still can not solve the problems, we can provide door to door services,
but need your help to pay the round-trip airfare and lodging expenses.
