APS-AR High-grade single color name card offset printing machine
A Suction feeder
B New type UV roller system
C Special AR water supply system
D Rotary removable ink fountain
E Electronic and mechanical register
Features
1,Adjustment Electronic with mechanical to ensure accuracy of printing
2,New Type AR water supply system to ensure the stability of water and ink’s balance.
3, New type Rotary removable ink fountain and ink scraper system are easy for the color changing and cleaning.
4,With the UV roller can not only print name cards, post cards, but also for small-lot of plastic card printing: PVC,PET and postcard etc.
5,Air suction system ensure the paper feeding stability.
Specification
Paper size | Min 45*80mm / Max 165*265mm |
Printing area | 165*225mm |
Paper thickness | 0.15-1.5mm |
Plate size | 220*230mm (thinkness:0.1-0.2mm) |
Precision of printing | Vertical : 0.01mm horizontal : 0.01mm |
Way of paper | 200mm |
Method of paper collection | Suction feeding with pushing claw |
Collection way | Belt deliver way |
Roller (UV) | Water roller : 5 ink roller 10 |
Way of run-edition | New AR damping plate |
Printing speed | 4000-8000 sheets/hour |
Dimension | L1000*W650*H900mm |
Machine weight | 124Kg |
Power | AC 100V 50/60Hz 1.2Kw |
