High temperature insulated cable heat resistant electric wire 1mm 1.5mm 2mm 2.5mm 4mm 6mm 8mm 10mm



DESCRIPTION

1. Nominal Voltage: 300V.

2. Temperature Range: -80°C to +200°C.

3. Conductor: Tinned copper.

4. Insulation: FEP.

5. O.D.Allowance: ±0.10mm.

6.Available:Black-Brown-Red-Orange-Yellow-Green-Blue-Purple-Gray-White-Transparent-Yellow/green,etc.

Conductor			Insulation		Electrical Characteristic		Packing
Section mm2	Conductor constructionN×mm	Diameter mm	Insulation Thickness mm	Inner Diameter mm	Conductor Resistance 20℃  ohm/km	Permissible ampacity   20℃-AMR	m/roll
0.14	7/0.16	0.49	0.30	1.09	143.00	3.15	400
0.20	7/0.20	0.61	0.30	1.21	89.30	5.04	400
0.30	19/0.15	0.76	0.30	1.36	56.40	7.98	400
0.50	19/0.185	0.93	0.30	1.53	35.20	12.78	400
0.75	19/0.23	1.16	0.30	1.76	22.20	20.27	400
1.00	19/0.26	1.31	0.30	1.91	17.52	32.14	400
1.50	19/0.32	1.61	0.30	2.21	11.99	40.54	400
2.00	19/0.37	1.86	0.30	2.46	8.78	51.25	200
2.50	19/0.41	2.06	0.30	2.66	7.17	64.56	200



CHARACTERISTIC

High temperature resistance, low temperature resistance, anti-acid, anti-oil, antisepsis and moisture, DIN VDE 0250, RoHS compliance.



APPLICATION

Apply to Household appliance, Illumination & Lighting & Headlamp, electric machines, temperature sensor, Military Series, Metallurgy Chemical series, Motor cars & Ships, Electrical Installation.
