 SY-C010 Medical Cheap Portable Fetal Monitor Price





SY-C010, is a high-end fetal monitor, and it offers the most advanced integrated monitoring for the delivery room in big hospital; private obstetrician's office; antepartum clinic. They are designed for use in moving situation covers the entire continuum of antepartum and intrapartum applications.



Features:

Light weight, space-saving, easy operation

Interface of parameters of FHR, TOCO, FM with digital and curve display

Battery indication, pregnant No. Display

7 inch TFT color screen folding up to 90 degree

Special high sensitive water proof probe

Built-in 152mm long life thermal printer, the life exceeds over 20 years.



Advanced DSP technology, realtime identify and measurement for FHR, accurate and reliable results



Multi-crystals, wide beam form high sensitivity ultrasound transducer, 1MHz pulsed wave, low ultrasound power, safer to the fetus

12 hours data storage which can be playback and printed

Fetal acoustic stimulator function, which can easily and safely wake up the sleeping fetus when monitoring



A standard patient event marker and a clinical event marking button to separately mark clinical events.

Wide range of applying voltage (100-240 V)

Manual / automatic fetal movement detection



3 in 1 transducers, avoid twisting.

Many alarm functions are included: The monitoring time over alarm, no paper alarm.

Optionals:

Twins monitoring

Maternal SpO2, NIBP, PR, ECG, RESP, TEMP







Specification

Fetal Heart Rate:

Transducer: Multi-crystals, pulsed doppler , high sensitive

Strength: <5mW/cm2

Working frequency: 1.0MHz

Signal processing: special DSP system and modern recognization.

Measurement range: 30~210 bpm



Alarm Range:

High limit: 160,170,180,190 bpm

Low limit: 90,100,110,120 bpm

Maximum audio output power : 1.5 Watt

Toco: Measurement range: 0~100 units

Resolution: 1

Fetal Movement: Button Hand Count ( Automatic cumulative number of movements

Maternal SpO2 measure: Measure scope : 70%~99%. Measure accuracy: ±3%

Pregnant HR Measure: Measure scope: 30bpm~240bpm. Measure accuracy: ±2 bpm

NIBP measure:

a) NIBP-SYS (6.7~32.0Kpa) (50~240mmHg)

b) NIBP-DIA (3.4~26.6Kpa) (25~200mmHg)

c) NIBP-MEAN (2.0~24.0ka (15~180mmHg)

NIBP Accuracy: ±1.1kPa (±8mmHg) or ±5% of the results, take the bigger one.

Maximum Mean error: ±5mmHg

Maximum Standard deviation 8mmHg

Pulse Rate Accuracy: Maximum Mean error: ±2bpm

Measure accuracy: ±2 bpm or ±5% of the results, take the bigger one.

Measure mode: Auto, Manual

Power: a.c.100-240V,50/60Hz or 8.4 Li-LON

Power Consumption: < 20W

Dimension: 295W×240D×73H(mm)

Net weight: 1.75kg

Working Environment: Temperature: 5~40°C. Relative humidity: 10~80%
