Features

XTX-6S,XTX-3S Series microscope can provide high resolution and sharp image.With built-in CMOS software,it's very easy for demonstration and analysis.The instruments are widely used in educational field and electronical industry.





Specification List

Specification List	Specification	Model
		XTX-6S-W	ZTX-3S-C2
Viewing Head	Inclined Binocular Head	♦	♦
	Head 360° Rotatable	♦	♦
	Built-in CMOS(1.3M Pixel)	♦	♦
Eyepiece	WF5×/φ16	◊	◊
	WF10×/φ20	♦
	WF15×/φ15	◊	◊
	WF20×/φ10	◊	◊
	SWF10×/φ123	◊	◊
	HWF10×/φ22		♦
Objective	2×/4×	♦
	1×/2×, 1×/3×	◊
	Zoom magnification 1×-4×		♦
Focusing	Coarse Focus Adjustment System	♦	♦
	Coaxial Coarse & Fine Focus Adjustment System		◊
Incident light	Halogen lamp 12V/10W	♦	♦
	LED lamp(3.2V20MA)×3	◊
	LED lamp 3.2V1W	◊	◊
Transmitted light	Halogen lamp 12V/10W	♦	♦
	LED lamp(3.2V60MA)	◊	◊
Brightness adjustable system		♦	♦



PS: ♦ Standard ◊  Optional
