Technical | |
Engine | |
Engine Type: | Single cylinder,wind-cooled,Four-stroke |
Displacement(ml): | 107 |
Bore X Stroke(mm): | 52.4x49.5 |
Compression Ratio: | 9.1:1 |
Max. Power(kw/r/min) | 5.2/8000 |
Max. Torque (N.m/r/min): | 7.2/5000 |
Max. Speed (Km/h): | ≥85 |
Lubrication: | Pressure ,splash |
Clutch Type: | Multiplate wet clutch, Manual |
Ignition: | CDI |
Starting System: | Electric start |
Transmission System: | Chain drive |
CHASSIS | |
Front Brake: | disk brake |
Rear Brake: | Drum brake |
Front Tire: | 70/90-17 |
Rear Tire: | 100/80-17 |
Battery: | 12V/5Ah |
DIMENSIONS | |
L X W X H (mm): | 2000*670*1080 |
Seat Height(mm): | 780 |
Wheelbase (mm): | 1360 |
Min. Ground Clearance(mm): | 130 |
Max. Permissionable Weight(kg): | 150 |
Rider Capacity: | 1 Person |
Dry. Weigth (kg): | 114 |
Engine Oil(L): | 1L SAE15W/40 |
Fuel Tank Capacity (L): | 4 |
Others | |
Packing Size (mm): | 1800×460×860 |
Packing Weight (kg): | 134 |
Container Loading(40HQ): | 96 |
Different angles
Different colors
Details
Packing
We have 2 different packing method, one is SKD, the other is CKD. One container can load more CKD than SKD. After customer get the bikes, SKD is easy assemble, but need more freight. CKD can save more freight, but need worker to assemble completely.
1. CKD mean Completely Knock Down, except engine, we pack all other parts in a carton, the carton made by plywood, steel strips fix fringe and corner.
SKD: steel frame + carton
CKD: wooden case
Loading
Pantera Group , one of the widely reputed and highly reliable exporter and wholesaler of motorcycles ,including dirt moto, cub motorcycle, chopper, street motorcycle, racing motorcycle . Some of our
competitive items are exported to different part of the world, such as C90 motorcycles are popular
in Morocco market and Forza are so hot in Tunisia market.
All products are brand new and ship straight our from the supplier. Then are offered with high
quality with competitive price. Should you be interested in any products , please let us know
your requirements, quantity, style and sizes.
Any questions from your will be attached great importance and solved in time. We sincerely
hope to establish business relations with your esteemed company.
Why Choose Us:
1.Good knowledge and rich experience on different market can meet special requirements.
2.Strong professional technical team and advanced technology ensures to produce the high, stable quality specialized motorcycle and electric bikes.
3.Provide all the details of this motorcycle to you during the mass production. your complaints and requirements are highly respects.
4..Special cost control system ensure to provide the most favorable price.
5.OEM service is welcome.
6.Our aim: ensure the satisfiction of the customers.
