Heat Insulation Vapor Barrier Aluminum Foil Radiant Barrier:





Different Form of Vapor Barrier Aluminum Foil Radiant Barrier:


alum foil products.jpg





Application:


(foil-scrim-kraft facing)


1. mainly used as facing for glass wool insulation, rock wool ,mineral wool and so on.


2.under roof decking, under attic rafters, over existing attic thermal insulation, in floors, walls and crawl spaces.


3. in industrial and commercial buildings to block radiant heat coming into house through the roof during the summer and retain indoor heat generated during in winter.


4.Reinforced with Tri-way fiberglass scrim also used as a moisture vapor barrier in air conditioning ductworks and cold rooms





Features:
1) With high tensile strength and bursting strength
2) Used as jacket facing for glass wool, rock wool, PU foam and other insulation to
protect them against vapor moisture, in order to work more effectively

Specifications:
1) FSK40A


a) Foil: 7μm
b) 2-way scrim: 12.5 x 12.5mm space
c) Polyethylene
d) Kraft: 50gsm, natural
2) FSK716B:
a) Foil: 7μm
b) 2-way scrim: 12.5 x 12.5mm space
c) Polyethylene
d) Kraft: 60gsm, natural
3) Roll width: 1.0, 1.2, 1.25, 1.30m
4) Roll length: 60, 120, 300, 500, 1600, 2750m

Outer packing:
60m roll: plastic shrinking sleeve
120, 300, 500m rolls: kraft cardboard
1600, 2750m jumbo rolls: corrugated board + ply-wooden pallet






T
echnical parameters:


























































Physucal Properties



Test  Method



Values (English)



Values(Metric)



Basis Weight



Scale



25.5lbs/1000 ft2



125g/m2



Tensile Strength



GB/T12914-1991






22.5lbs/inch(MD)



3.79 kn/m(MD)



13.9lbs/inch(XD)



2.31 kn/m(XD)



Bursting Strength



GB/T454-2002



36 lbs/psi



248 kpa



Water-resitant



23 °C 24h



No phenomenon of layered



No phenomenon of layered



Low-temperature resistant



-40 °C 1h



No phenomenon of layered



No phenomenon of layered



High temperature


resistant



116 °C 4h



No leakage phenomenon



No leakage phenomenon



Thickness



Micrometer



0.0058 inch



150 micron









IKING Vapor Barrier Perforated Aluminum Foil Showcase





Production Lines


production line.jpg








Warehouse


aluminum foil warehouse.jpg








Packing and loading


aluminium foil packing.jpg





IKING Laboratory








Our Services









We exported 400x40''HQ to oversea market 2014 years. Now we are looking for serious agency for IKING aluminum foil in different country. If you are interested in us, please feel free to contact with us.We welcome you visit our factory any time!!!
