Высокая точность машины плазменной источник газорезательный станок с

Описание и отзывы

Характеристики



Model	FX-450LMX3060HD
Cutting method	Plasma	Flame(Optional)
Cutting size	2530*4000mm
Machine size	3650*6000mm
Lifting travel	≤170mm
Max travel speed and cutting speed	10000mm/min 0-15000 mm/min
Running accuracy	≤0.005mm	≤0.1mm
Height control	Arc pressure THC	Lifting body
Cutting thickness	According to the power supply,	6-200mm
cutting gas	air	Oxygen + ethyne(Propane)
Gas pressure	0.4-0.8Mpa for normal plasma power
Drive system	Dual drive
Stepper motor	Stepper motor and driver
X, Y axis	High Quality Rack & Pinion and 18kg linear rail
Auto ignition	AR235(optional)
Power Voltage	380V    50HZ
No. of cutting torch and nozzle	1 set of plasma/flame cutting torch, 10 pcs nozzles
Software	STARCAM





Q1: I knew nothing about this machine, what kind of machine I should choose?

Very easy to choose. Just tell us what you want to do by using CNC plasma machine, then let us give you perfect solutions and suggestions.



Q2: When I got this machine, but I don’t know how to use it. What should I do?

We will send video and English manual with the machine. If you still have some doubts, we can talk by telephone or whatsapp and e-mail.



Q3: If some problems happen to this machine during warranty period, what should I do?

We will supply free parts during machine warranty period if machine have some problems. So any doubts, just let us know, we will give you solutions.



Q4: Before sending me an inquiry on our plasma, it is better for you to provide me the following information

1)Your cutting size. Because in our factory, we have different models according to working area.

2)Your materials: Carbon steel, stainless steel , aluminum, or other materails

3) what’s your cutting thickness?

We will recommend suitable power source to you according to your cutting thickness



Q4: Our Service:

1) 24 Hours online service. my whatsapp: 15165193115

2) 12 months warranty for the whole machine except for wearing parts.

3) Engineers available to service machinery overseas.
