Four colors Offset Printing Machine, plastic cup printer

Product Description

Usage:

The Four colors Offset Printing Machine, which feeds cups on level and adopts corona pre-treatment, mandrel UV curing, so printed pattern is clear and real. Main motor mounted with three-phase frequency conversion speed adjust, timing belt drive, stepless speed regulation, functions steadily without noises. Convenient to adjust quantity of ink and pressure of ink distributing roller, and the ink supply is ideal. when fix forme, locating spring can automatically tighten, and it is easy to load or unload the forme, as well as chromatography. printing cylinder and forme roller assembled with cantilever are easy to cluch and adjust pressure.

Features:

The cups will be delivered to the channel by the cup-serving-tray automatically, which could reduce labor intensity. The cup-delivering channel will be powered by electronic engineering sharing the same speed with pressing. The cup-delivering tray(spiral wheel) is special designed for many kinds of cups, and it could be set for45⁰ or 90⁰ according to your special need.

Techinical Specifications:

1. Product specification

This type is the letterset printing machine, with axes UV solidification, suitable for printing on plastic cups and bowls.

2. Printing diameter

30~146mm

3. Requirements for the size of the cups or bowls

50~168mm

4. Maximum printing height

110mm

5. Height of cup

30~150mm

6. Bevel of cup or bowl
