Product Description


The crane is a hydraulic slewing and luffing crane ,for lifting a variety of marine debris and marine life,loading and unloading cargo or other special purposes.

Marine Hydraulic Slewing crane is composed by the cylinder , the fuel tank,crane hoisting mechanism and jib luffing mechanism .And lifting ,rotating,jib luffing are driven by hydraulic system.


Advantage - Marine Stick Fixed boom Floating Crane For Sale
 * Flexible and reliable action
* Easy to operate
* Uses a wide range of characteristics .
* Suitable for operations at sea .








Type
Rated load
(SWL)
Max.work
radius
Lifting speed
M/min
Swing speed
(r/min)
Amplitude time
(m)
Lifing height
(m)
Rotary range
(°)
Allowing
inclination
(trim.heel)
Power
(KW)






QY
0.5
5-12
15
1
60
30
360°
2°/5°
7.5
1
6-12
15
1
60
30
360°
2°/5°
11
1.5
6-14
15
1
60
30
360°
2°/5°
11
2
8-16
15
1
60
30
360°
2°/5°
15
3
8-18
13-15
0.8
70
30
360°
2°/5°
22
5
10-20
12-15
0.75
80
30
360°
2°/5°
37
8
12-20
10-15
0.75
100
35
360°
2°/5°
55
10
12-20
10-15
0.7
100
35
360°
2°/5°
75
15
12-22
10-15
0.6
110
35
360°
2°/5°
90
20
16-25
10-15
0.6
120
40
360°
2°/5°
125


Different Types


fold arm marine deck crane
straight arm marine deck crane
wire rope luff deck crane


Packing&Shipping


steel structure packing by plastis film
small parts packing by wooden case




After Sales Service


1. We are available to design and make deck crane at request of clients.
2. We are professional to reply clients within 24 hours.
3. Our engineers are available to make installation, commissioning oversea.


Company Introduction


Xinxiang Weiying Machinery Co., Ltd.
Xinxiang Weiying Machinery Co., Ltd. Located in Xinxiang City,Henan province, the crane hometown of China with convenient transportation access . All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world .

We have rich experience on Design ,Develop. Manufacture and Export industry crane Equipment. Mainly produce overhead crane ,gantry crane ,jib crane , marine deck crane and other marine crane products.

We knowevery details about the crane equipment application in every industries ,Here in China , We are top of line ! We could supply you all kinds of industry cranes from 0.25 tons to 300 tons ,pass GB/T 19001-2000 / ISO9901:2000 GB/T24001-2004 / ISO 14001:2004,GB/T28001-2001 ,OHSAS18001:1999 ,CE and So on








Recommend Products


 Boat load crane
RTG rubber Wheeled container load crane
rubber tire single gantry crane


load/unload container crane
Engineering construction road building gantry crane
RMG Rail mounted container load crane


Basic informations for inquiry




Thanks for your time , In order to sending you right price , Please imform us your detailed needs for marine deck crane .
* 1. the crane load capacity ?
* 2.the lifting height ?
* 3.the arm lenght ? or working radius ?
* 4. the working voltage ?
* 5. add your other demand ...
