15 мм 20 30 50 Свободный резиновое покрытие полые из нержавеющей стали мяч для

Описание и отзывы

Характеристики



Specifications

1) Size: 0.3mm--20mm
2) Grade: G40--G500
3) Hardness: HRC 61--66
4) Complying with GB, ASTM, DIN, JIS standards

Features:

1. Materials:  AISI52100, GCr15, SUJ2, GCr15SiMn, 100Cr6 and so on


2. Grades:  G40,  G60,  G100,  G200,  G500


3. Size:  0.3mm--20mm


4. Complying with GB, ASTM, DIN, JIS standards


5. Use:  Hardware, bearing, machinery, guide rail, guide sleeve, grinding compound, polishing, fine powder, aluminum powder aluminum aluminum paste, decoration, toy domain and so on


6. Packing:  plastic bag, export carton, pallet or steel barrel, steel drum;According to customers' requirements

Grade information

GRADE	Ball Dia. variation		Deviation from spherical form (U)	Surface roughness (U)	lot Dia. variation (U)	Basic Dia. tolerance (U)
	INCH	(U)
3	0.000003	0.08	0.08	0.012	0.13	±0.75
5	0.000005	0.125	0.125	0.02	0.25	±1.25
10	0.00001	0.25	0.25	0.025	0.5	±2.5
16	0.000016	0.4	0.4	0.025	0.8	±2.5
24	0.000024	0.6	0.6	0.05	1.2	±2.5
48	0.000048	1.2	1.2	0.08	2.4	±5
100	0.0001	2.5	2.5	0.125	5	±12.5
200	0.0002	5	5	0.2	10	±25
500	0.0005	12.5	12.5	-	25	±50
1000	0.001	25	25	-	50	±125
2000		50	50	-	100	±125



Material Comparison List

State	China	Japan	America	Germany	France
Standard	GB	JIS	AISI	DIN	NF
Title	GCr15	SUJ-2	52100	100Cr6	100C6
Title	GCr15SiMn	SUJ-3		100CrMn6



 Please contact us .More surprises awaiting for you.
