Новинка 2015 Четырехцветная офсетная печатная машина ZR462IINP легкая

ZR462IINP

ZR462IINP four color Light offset printing machine price

Model

ZR462IINP

Max. sheet size

620 × 450mm

Min. sheet size

260 x 180mm

Max. print format

605 × 440mm

Plate size

620 × 485 × 0.15mm

Blanket size

616 × 505 × 1.95mm

Paper size

45-250gsm

Max. speed

7000 sheets/hour

Molleton

thick: 76 stitches; thin: 44stitches

Numbering device

Straight type(horizontal): 56 heads Max.
(7 heads on a ring × 8 rings on a shaft)

Convex type(vertical):   45 heads Max.
(5 heads on a ring × 9 rings on a shaft)

Letter press device

Cylinder type: 90 × 345mm Max.

Mounting ring type: 30 × 40mm Max.

Perforating device

Cross perforation: Min 25mm

Vertical perforation:5mm(blade-perfo type)
                   2cm(rotary-perfo type)

Ink rollers for NP unit

6pcs(2 forme inking rollers)

Speed adjustment

Frequency converter

Gripper margin

8-10mm

Inking rollers

14pcs per unit(3 forme)

Dampening rollers

4pcs per unit(1 forme)

Power supply

380v/50Hz

Main motor

4kw

Air pump motor

1.5kw

Machine dimension

4550(L) × 1040(W) × 1460(H)mm

Net weight

3260kg

Package dimension

4950(L) × 1150(W) × 1720(H)mm

Gross weight

3700kg
