Machine Dimensions

600X510X480mm

Rack material

6061 and 6063 Hard aluminum alloy
(The unique and dedicated mold extrusion profiles, Let counterfeiters dwarfs.)

Engraving area

400X300mm

Z-Axis Stroke

80mm, Engraving depth depends on the length of the tool edge

Acceptable material thickness

≤80mm

Rail type

Chromeplate shaft + Linear Bearings, Surface hardening 61HRC

Type of screw

Ball screw 1605, Pitch 4mm

Spindle motor

800W VFD water cooling spindle , 0-24000r/min

Collet type

ER11,1/8"(3.175mm) Collet

Stepper motor and drive

two-phase hybrid stepping motor 57BYGH56-4011YD, 8 segments drive.

Maximum operating speed

4000mm/min (Engraving speed :300-3000mm/min)

Repeat positioning Accuracy

0.03mm

Communication interface

Parallel port

Software Compatability

Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam)

Command code

G code/.nc/.ncc/.tab/.txt

Machine weight

50kg
