RL-S7210GFProductSPEC





RicherLinkgigabitL2managedswitchRL-S7210GFprovides810/100/1000Mbpsports and 2 gigabit SFP slots.Theswitchprovidessecurityperformance,qualityofservices,flexiblylayer2managementfeatures. Moreover,with 2 gigabit SFP slots expands your network flexibly.

RL-S7210GF supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring, Storm Control, STP/RSTP, Link Aggregation Control and 802.3x Flow Control function. Any more, the switch provides advanced features for network maintenance. Such as Self-Loop Back Detection, IGMP Snooping . IGMP snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Self-Loop Back Detection detect two ports direct link or the network loops on single port, Self-loop and RSTP function provide a secure and stable network environment, to achieve complete loop-free network .

RL-S7210GF is easy to use and manage. It supports various user-friendly standard management features,such as intuitive web-based Graphical User Interface(GUI) or Command Line Interface(CLI). SNMP (v1/2c) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events.

Another important feature is RL-S7210GF supports RPS power function.and the adapter power can charge for the redundancy battery power.

n       Product Specifications

ITEM	Description
Interface	8 10/100/1000Mbps RJ45 Ports(Auto Negotiation/Auto MDI/MDIX) 2 1000Mbps SFP Slots 1 Console Port
Bandwidth/Backplane	20Gbps
MAC Address Table	8K
Packet Forwarding Rate	14.9Mpps(64-byte packets)
Jumbo Frame	9k Bytes
QoS	Support 802.1p CoS/DSCP priority Support 8 priority queues per port Queue scheduling: strict priority(SP), deficit weighted round-robin scheduling(DWRR) Full-duplex flow control (IEEE 802.3X) and half-duplex backpressure
STP	Standard Spanning Tree 802.1d(STP) Rapid Sanning Tree 802.1w(RSTP)
VLAN	Supports up to 16 VLANs simultaneously (out of 4K VLAN IDs) 802.1Q tag-based VLAN Port-based VLAN Port Isolation Management VLAN configuration
IGMP Snooping	Support IGMP Snooping V1/V2 for multicast groups
Port mirror	Per-port ingress and egress mirroring
Trunking	Static trunk (Link Aggregation) Up to 5 groups  and Up to 10 ports per group
Broadcast Storm  Control	Generic storm controllers for flooded broadcast, flooded multicast, and flooded unicast traffic
Loop detection	Support the loop detection for easy maintenance method to solve network failure problem.
Management	Web-based GUI and CLI management SNMP v1/v2 RMON (1, 2, 3, 9 groups) Firmware Upgrade: TFTP & Web Dual Image
Power	9-15V /1A
RPS Power	12V battery
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
