Product Description
Our Suction Units are appreciated, recommended and imported by several countries. We have range to suit every application and situation including: portable suction units & machines, wall suction, pipe suction on trolley, electric and manual suction units and handheld units.
Emergency Wound Drainage Surgical Suction Unit with battery
Features
Wound Continuous Drainage Suction Unit when used for drainage or clean-up the surface wound cooperated with special dress:
Bedside drainage with noiseless;
There are two modes of operation, Continuous and Intermittent, Intermittent mode working time can be set;
High-life and long-time continuous work without fault.
Vacuum can be regulated according to requirements. High-precision pressure sensor makes the vacuum value constant and reliable
Overflow protection device can protect the pump against pollution by the liquid.
Relief valve is used to reduce vacuum value when it is adjusted from high to low as well as the vacuum value that rises suddenly in the tube.
It works with Low-vacuum light and High-vacuum sound-light alarm.
Product Features:
1. Two operation mode: Continuous and Intermittent, working time of Intermittent mode can be set;
2. Adopt oil-less pump, high vacuum, low noise;
3. Vacuum regulator can be locked and controlled as needed.
Specifications:
1. Max. Vacuum: 50KPa± 10%(375mmHg)
2. Vacuum range: 6KPa(45mmHg)~Max. Vacuum
3. Flow rate: ≥ 8 L/min
4. Noise: ≤ 55dB(A)
5. Working mode: Continuous and Intermittent
6. Intermittent working time: 5 min ON/2 min OFF (default) or set from 1~15min
7. Power supply: ~110V~240V, 50/60Hz; DC 12V
8. Input power: 40VA
9. Storage bottle: 800ml
10. G. W. /N. W.: 4.5kg/3.5kg
11. Dimension: 39cm× 19cm× 34cm
Max. Vacuum: |
50KPa± 10%(375mmHg) |
Power supply: |
~110V~240V, 50/60Hz; DC 12V |
