M16 Series IP67 IP68 2 3 4 5 6 7 8 12 14 19 24 Pin M16 Circular Connector
Product Description
| Product Description |
Characteristics of M16 Series
| General Characteristics | |||||||||||||
| Number of contact | 2 | 3DIN | 4 | 5 | 5DIN | 6DIN | 7 | 7DIN | 8DIN | 12 | 14 | 19 | 24 |
| Locking system | screw M16*0.75 | ||||||||||||
| Termination | solder, moulded on cable | ||||||||||||
| Wire guage in mm² | max 0.75 | max 0.25 | 0.14 | ||||||||||
| Wire guage in AWG | max 20 | max 24 | 26 | ||||||||||
| Shell protection | IP67/IP68 | ||||||||||||
| Mechanical operation | >500 mating cycles | ||||||||||||
| Upper temperature | +85℃ | ||||||||||||
| Lower temperature | -25℃ | ||||||||||||
| Electrical Characteristics | |||||||||||||
| Rated voltage | 250V | 60V | 250V | 125V | 60V | ||||||||
| Test voltage | 1750V | 550V | 1750V | 910V | 550V | ||||||||
| Rated current(40℃) | 7A | 6A | 5A | 3A | 1A | ||||||||
| Pollution degree | III | ||||||||||||
| Contact resistance | ≤5mΩ | ≤3mΩ | |||||||||||
| Insulation resistance | ≥10³MΩ | ||||||||||||
| Materials | |||||||||||||
| Pin contact | CuZn | ||||||||||||
| Socket contact | CuSn | ||||||||||||
| contact plating | Au | ||||||||||||
| Upper temperature | PA66(UL 94V-0) | ||||||||||||
| Female insent | PA66(UL 94V-0) | ||||||||||||
| Material of cable jacket | PVC or PUR | ||||||||||||
| Screw | CuZn | ||||||||||||
| Nut | CuZn | ||||||||||||
Packaging & Shipping
| Packaging & Shipping |
1. Packaging:
Cartons
Size : 46cm*30cm*25cm
30cm*30cm*13.5cm
26cm*21cm*10cm
PS :Label can be customized based on customers' requests
2. Logistics:
>>>>>>>>>> Contact us now <<<<<<<<<<
Our Services
| Our Services |
- Fast Samples delivery service
- Quote within 24 hours
- Professional teams with RD & Sales for your projects
- Special service for your urgent case
- Customer is always our focus.
Company Information
| About Us |
Shenzhen Signal Electronics Co., Ltd is located in Shenzhen since 2009, We are professional in manufacturing, researching & developing world-class, high quality industrial connector. With our strong R&D ability, flexible production lines, we can also providing complicated cable harness and customized solutions.
Our goal is to become your reliable OEM / ODM partner for all your inter-connectivity solutions. We recognized Signal only can be successful with partners that share the same values and drive to deliver high quality and createmaximum customer satisfaction.
FAQ
| FAQ |
| Q | When can I get the quotation? |
| A | Within 24Hours after we get your inquiry. If you are very urgent to get the price, |
| please call us or advise in your e-mail so that we will quote to you in priority. |
| Q | What is the minimum order quantity (MOQ)? |
| A | 100 pcs or negotiate. |
| Q | What kind of certificates SIGANL have? |
| A | RoHS 2.0; REACH; UL; TUV; CE; IP67/68; IP69K; ISO9001:2015; ISO14001:2015… |
| Q | How long can I expect to get the samples? Should I pay for the samples? |
| A | The samples will be ready to delivery in 3-7 days after you confirm the drawing. |
| For standard products, you can get 2-4pcs free samples. |
| Q | How about freight cost? |
| A | You can use your express account to ship or prepay the freight cost to our bank account or |
| Paypal account. |
| Q | Can you provide customized products for us? |
| A | Yes. We have a professional team in providing customized solution for you. Just tell us your |
| idea and the related information you have, then we will help to carry out. what kind of | |
| information you should provide, just contact our sales, we will tell you. |
| Q | What about the lead time for mass production? |
| A | Honestly, it depends on the order quantity and the season you place the order. The lead time |
| of MOQ is about 10 to 15 days. Generally speaking, we suggest you start to inquiry two | |
| months before the date you would like to get the products at your country. |
| Q | How many materials you can provide? |
| A | For connector, we have plastic & metal materials. For cable, PVC & PUR jacket are available. |
| Rubber/PU/PE/Silicone materials are used in cable. Of course, we can also provide the | |
| materials based on your requirements/applications. |
