High quality port crane manufacturers

Portal crane from manufactuers applications are: loading and unloading at port, material
handling at dockyard, ship building and repairing yard, metallurgy industry. They mainly indclude lifting mechanism, luffing
mechanism, slewing mechanism, travelling mechanism, spreader device(grab, container, hook),
electrical equipment and other aiding devices for safety. The applied rigid rack and screw lever luffing mechanism make sure a constant working state.

Pictures of the portal crane from manufacturers:

Specifications:

Type		MQ	MQ	MQ	MQ	MQ	MQ	MQ	MQ	S4070		S5035		S8035
Type		525	533	1025	1033	1625	1633	2533	4033	K10		K10		K10
Cap/t		5	5	10	10	16	16	25	40	40	70	50	38	80	38
Lift/M	Max	25	33	25	33	25	33	33	33	65	28.5	35	14	35	14
Lift/M	Min	8	9.5	8	9.5	8.5	9.5	9.5	9.5	24	45	11.5	40	11.5	40
Lift Height/m	Up	12	15	15	20	20	28	28	28	45	13	40	0	40	0
Lift Height/m	Down	9	9	9	12	12	15	15	16	13		0		0
Span*Base/m		10.5*10.5								10.5*18.5		12*10.5
Speed	Hoisting	40	50	50	50	50	60	60	50	15		7.5		6
(m/min)	Luffing	24	40	50	40	40	40	50	50	17		12.8
	Slewing	1.5	1.5	1.5	1.4	1.5	1.5	1.5	1.41	0.26		0.4		0.4
	(r/min)	1.5	1.5	1.5	1.4	1.5	1.5	1.5	1.41	0.26		0.4		0.4
	Travel	25								26		25
Max Wheel Load/KN		180	210	220	185	240	250	260	260	260		250		250
Capacity/t		280	300	330	345	325	345	435	560	400		250		320
Ship/DWT		19000	30000	190000	30000	190000	30000	30000	30000	100000		30000

Packaging & Shipping

1. Electric parts are packed by high quality plywood crate, to reduce distortion in conveying;
2. Main beams, end beams and electric hoist are packed by plastic woven cloth. It can reduce abrasion when transport.
Shipping:
(1) If the size of whole crane are suitable for container ship, usually by container;
(2) If the size is too big, usually by bulk ship or by container after truncation;
(3) Transport ways are based on reducing cost for you and keep the crane performance.
