station rework bga and soldering stations ZM-R720 infrared soldering station to repair BGA&LED
Features
1. Suitable for LED lamp beads repairing, size of micro LED components not less than 0.6*0.6mm can be repaired
2. Suitable for LED lamp beads of tape packaging and bulk materials, Also any BGA and components which are difficult to repair.
3. High solution optical alignment system, accurate LED components positioning, ensure precise mounting.
4. Optical alignment is controlled electrically, can rotate automatically
5. Mounting head built-in pressure testing device, to protect the PCB
6. Built-in infrared laser positioning, fast positioning for PCB.
7. Adopt HIWIN precision guide rail for up and down movement system, ensure reliable and accurate running.
8. Adopt up and down alignment for top and bottom heater, heating for appointed local zone, prevents PCB to turn yellow.
9. Bottom heater up and down manually can adjust the heating height real time.
10. Adopt ceramics infrared radiator for IR heater, heating stably and uniformly with long serves life
11. Human-machine interface has multiple operation mode and permission, soldering, desoldering and mounting manually, easy operation.
12. High resolution touch screen, which is up to 800*600 pixels
13. Adopt joystick control for alignment system, no need setting complicated parameters
14.Adopt Delta double ball bearing flow fan for air supply,no need external air source
15. Adopt DCCE 6 channel module for temperature control system, automatic PID adjustment
16. Monitoring heaters real time, when accident happens, relevant sensors will send signal to PLC, which will close output channel and display fault condition. Protect it automatically.
Main technical and parameter
Total Power | Max 5300W |
Power | AC 220V±10% 50/60 Hz |
Top heater power | 1200W |
Bottom heater power | 1200W |
IR power | 2700W |
Hot air temp | 400℃ (Max) |
Preheating temp | 400℃(Max) |
Positioning | V-groove +laser positioning+ universal fixture |
PCB size | Max 410×370 mm |
Preheating size | 370mm×270mm |
Chip type | BGA, QGN, CSP, POP, QFN, Micro SMD, LED lamp beads |
Chip size | Max 80×80mm Min 2×2 mm |
Dimensions | L640×W630×H900 mm |
Temperature sensor | 1Pc |
Net weight | 70kg |
Color | brown/milk cream |
Customers Visit
FAQ
1: Why choose us?
First of all, quick respond, save your time, time equals money, so we save money for you. see, you are already saving money, even you contact us.
2: Should I worry about the quality?
My dear friend, our company joined the Alibaba Trade Assuracne, if you got defective goods, we got Alibaba on our tail, that's not what we want, and that's not how we do business.
3: How's about the transportation?
If you ask this question, I guess that you missed the picture above. DHL, FedEx, UPS, TNT, and so on, tell us which one you don't like, we will keep that in mind.
4: How do I pay?
My friend, there are many ways. T/T(we prefer this one), Western Union, PayPal, choose your favorite one.
5: How's after-sale service?
If, unfortunatly, you received defective goods, ah oh, this is an unpleasant situation, no one want it. But don't you worry about it, problems come out, we will be there to make it disappear. Believe us, it will be a happy ending.
6: How to operate the equipment?
My friend, don't worry about it, we have made vedio for your, it will show you how to do it step by step.
