100-347v t8 led tube light 18w plug and play tube



An excellent replacement for 4’ T8 or T12 fluorescent tubes



Features:

1.100-347v Works with the vast majority of T8 and T12 ballasts.



2.Even light distribution with a 120 degree beam angle



3.50,000 hour lifespan, more than 10 years in most applications



4.Design Lights Consortium approved with 3 year warranty



5.Provides more light than a 32 watt fluorescent tube while reducing electrical consumption by 44%



6.Does not contain Mercury or other toxins



7.Avoid initial labor cost by replacing the fluorescent tube with this compatible tube. Once a fluorescent ballast fails, there is no need to install a new ballast.



8.This tube can simply work with direct A/C power. Ideal for offices, showrooms, refrigerators, cover lighting, etc.



9.T-8 LED lamp operates on line voltage with existing electronic ballast or without a ballast; one socket wired to line voltage, or both ends.



10.Heat sink: 6063 extruded aluminum with heat dissipation ribs for superior thermal management



specifications:

        1.Tube Power: 18W;



 2. Lube Luminous Flux(lm): 2160-2700LM;



 3. Lamp Luminous Efficiency(lm/w) :120-150LM/W.



 4. CRI(Ra>):>85;



 5. Input Voltage: 100-347Vac;



 6. Certification:UL DLC  ETL CE RoHS;



 7. Color Temperature(CCT): 2700K,3000-3500K, 4000-4500K, 5500-6000K;



 8. Base Type: G13/FA8/R17D



 9. LED Light Source: Epistar Chip.



10. Warranty: 3 years;



11. Working Lifetime(hour) 50000;



12. Working Temperature(°C): -40-50;



13: Lamp Body Material: Aluminum;



14: Cover : Clear or milk ;



15: Size: Diameter 25.4*1200mm.



DLC Model NO:SPZT8B418T











Physical Specification
Light Source	Epistar
Size	Diameter 25.4*00mm.
Weight	200g
Material	Aluminum Housing+ PC Lens(Transparent ,stripped or Milky)
Operation Temperature	(-20)~40°C (-4~104°F)
IP Grade	IP44
Electrical Specification
LED Power(W)	18Watt
Suggested Replacement	18Watt Traditional Fluorescent Tube
Power Efficiency	>85%
Input Voltage	100-347V AC
Frequency Range	50 ~ 60 Hz
Life Span	>5years
Optical Specification
LED Luminous Efficacy	120-150lm/w
Total Lumen	WW:810 lm	PW:900lm	CW:980 lm
Color Rendering Index(CRI)	Ra >80
Luminous Decay	<4% at 3000 H
Beam Angle	The Horizontal Axis 120° The Vertical Axis 60°
Illumination ( E )	(Height=1 m ) = 121lux
	(Height=2 m ) = 30.3lux
	(Height=3 m ) =13.5lux
Effective Illuminated Area	(Height=1 m ) = 2.1 x 2.2m
	(Height=2 m ) = 4.8 x 2.6m
	(Height=3 m ) = 7.8 x 4.6m
Temperature Color	Warm White(WW): 2700~3500K
	Pure White(PW): 4000~5500K
	Cool White(CW): 6000~7000K
Packing Information
Packing	Foam Protection or paper box
Packing Quantity	40 pcs/carton
Carton Size	125*27*17cm
Carton Gross Weight	13kg
Container Loading QTY	16000pcs/20'GP, 32000pcs/40'GP



100-347v t8 led tube light 18w plug and play tube







1. Promptly reply within 24 hours



2.Well-trained, professional and experienced salesmen with good English



3.OEM&ODM are welcomed



4. Factory offers 3-5 year warranty for our LED lights.



5. Factory will responsible to maintenance or replace any defective products within warranty period.



6. Factory will keep secret for your sales area, design ideas and all of your private information.









1. Payment terms: T/T 30% deposit in advance, the balance of 70% before delivery;



Western Union and Paypal for small amount are accepted also.



2. Delivery time: 3-5 days for samples, 7-12 days for normal order



3. Shipment: UPS/DHL/FEDEX/TNT or sea shipment.



4. Shipping port: Shenzhen



5. Discounts are offered based on order quantities.

 100-347v t8 led tube light 18w plug and play tube
