Гигабитный Инжектор POE 48 В постоянного тока адаптер питания 12 3 А источник для беспроводных сетевых

Описание и отзывы

Характеристики

 passive  POE injector / Power-Over-Ethernet ( RJ45 POE) adapter / POE Splitter  /POE power supply for  POE Switch/ Security Cameras /IP phone



Model Number	GRT-480065A-DC
Input  Voltage	41-57Vdc
Input Current	1.5A max.
Input Inlet	2* power wires or 2* screw terminal blocks
Output Voltage / Power	48Vdc 32W
Output type	Single outputa 1*RJ45 connector ---POE 1*RJ45 connector ----LAN
Ethernet speed Pin assignment	10/100/1000Mbps Gigabit Ethernet Pin 12/36 & 45/78, 4 pairs
Network Protocol (IEEE802.3)	Non-compliance
Material	Plastic
Approval	CE/ROHS/FC
Warranty	3 year
Output Ripple	1% Max
Efficiency	≥88%, Meets Level 6
Response Time	<1ns
Combined Load Regualtion	±3%
Combined Line Regualtion	±5%
LED indicator	Power on, Green   (With Plastic enclosure)
Operating Temp	0 to 40℃ (32 to 104℉)
Storage Temp	(-)20 to 85 ℃  ( -22 to 158 ℉)
Operating Humidity	10~ 90% Non condensing
Shipment	By Sea or By Air Express: DHL/UPS/TNT/FEDEX ect
Package	Inner white box + Outer box
Carton Size:	460*390*200mm  (L*W*H)
Qty/ Carton	50-100pcs

* Support long distance for data, upto 100meters

* Data and Power passed by the ethernet cable

* Full protection:Overload/Over current/ Over voltage/ Short circuit

* Application: IP Phone, Voip Phone, Wireless Networks Access Points, IP print servers, Blue tooth access points , Security Cameras, smart door systerm  and more



POE injector / Power-Over-Ethernet ( RJ45 POE) adapter / POE Splitter /POE power supply for POE Switches, CCTV cameras, Voip Phone,IP phone ect



Type	Input Voltage.		Output Power	Ethernet Support		IEEE802.3 Protocol			AC inlet
	DC input	AC input		100Mbps	1000Mbps	IEEE802.3AF   (15W / port)	IEEE802.3AT  (25.4W / port)	Non-complianc 3AF/3AT
POE20	41-57Vdc	100-240Vac,50-60Hz	30W max	√	√	X	X	√	C6,C8
POE40	41-57Vdc	100-240Vac,50-60Hz	48W max	√	√	√	√	√	C6,C8
POE28	41-57Vdc	100-240Vac,50-60Hz	60W max	√	√	√	√	√	C6,C8,C14
POE 30	41-57Vdc	100-240Vac,50-60Hz	60W max	√	√	√	√	√	C6,C8,C14
POE 70	41-57Vdc	100-240Vac,50-60Hz	85W max	√	√	√	√	√	C6,C8,C14







About GREAT:



*. Offer OEM service, accept print your own logo and special requirements for package and others



*. Experienced Techncial team, to provide kinds of solutions



*. Provided authorized certifications



*. 100% Full Burn-In Testing, stictly inspect and control during production



*. 1-3 Year warranty



*. Owned kinds of Testing machines: Burn-in Room,High & Low  Temperature Tester, Performance testing instrument, Salt spraying tester,Drop tester ect.
