Delicate Multiple Functional LED Light Mirror Touch Sensor Switch
membrane switch
membrane keypad
membrane keyboard

- Membrane switch is a operating system of key function, indicating element and instrument panel brought together. Membrane switch is also named light touch keyboard, using planar multilayer combination sealing structure as a whole. It is a new type of optical, mechanical and electrical integration of electronic component. It can replace the keys of conventional discrete component , more reliably operating system tasks.
- Membrane switch panel is the main type of membrane switch, made of the basis of rigid or flexible printed circuit board, installed tactile or non-tactile buttons and plastic membrane overlay printed with colorful decorative pattern. It is a new type of human conversation interface. The connection between the switching circuit with the machine can be completed by the splicing or welding method.

Membrane Switch Techinical Parameters:
Operating Voltage | ≤50V (DC) | Insulation Resistance | ≥100MΩ (100V/DC) |
Operating Current | ≤100mA | Recoil Time | ≤6ms |
Contact Resistance | 0.5~10Ω | Loop Resistance | ≤100Ω |
Service Life | >1 Million | Standard Of Pitch | 2.54/1.25/1.0/0.5mm |
Switch Stroke | 0.1~1.0mm | Operating Force | 15~750g |
Operating Temperature | -20~+70°C | Storage Temperature | -40~+85°C |


- Precise structure, good-looking appearance, tight sealing
- Moisture-resistant, waterproof, dustproof, oilproof, gasproof
- Light weight, small volume, long service life
- Stable and reliable performance, easy installation





Shenzhen Zhongman Technology Co., Ltd. is the wholly-owned subsidiary of HongKong Zhongman Technology Co., Ltd. We specialize in the R&D and manufacture of connectivity control solutions, and have our own brand “Vmanx”.
Our main products are connection controllers, including membrane switches, capacitive touch panels, PCBA modules, connecting wire harnesses, control keypads, etc.

Vmanx owns a group of excellent talents in the industry. From electronic engineering, software development and physical design, we are committed to meet customer’s demands for electronic engineering, function effectuation and aesthetic design, to provide customers with efficient and satisfactory technologies and services.
