Thickness of steel platen | 40mm |
Split type | Split and combination type |
Height of up and bottom beams | 1000mm |
Daylight | 1800mm |
Height of movable beam | 400mm |
Width of column | 400mm |
Overall size | 3600 *1370*5000 |
Weight | About 20 Tons |
Diameter of main oil cylinder | Ø360mm |
Stroke of main oil cylinder | 1000mm |
Number of main oil cylinders | 2pcs |
Max. pressure | 26MPa |
Max. Total Pressure of main oil cylinder | 600T |
Diameter of lifting oil cylinder | 90mm |
Stroke | 1000mm |
Number | 2 pcs |
High pressure pump | 25ml |
Motor of high pressure pump | 11kw |
Hydraulic integrated system | 1 set |
Pre-sale
1.Free consultation about the equipment.
2.Reasonable purchasing plan and the production line designing plan are offered according to the clients' special requirment to help you to select the most suitable machinery.
3.Welcome to visit our factory and check our machine.
During-sales
1. We inspect and test the machine before delivery.
2.We are willing to freely tran your technicist and first-line operator.
After-sales
1.Engineers are available to service overseas.
2.Videos about installing and debuging the equipment.
Sinoeuro Group is a manufacturer of wood working machinery with well equipped testing facilities and strong technical force.
1. Leading manufacturer of woodworking machinery in China, found in 1994. specialize in this field for more than 20 years.
2. Almost 20 year export experience, exported dozens of countries in Asia, Europe, Africa and America. All products are quite popular among clients.
3.Specializing in plywood production line and finger joint board production line. We have our own designers to meet any of your requirement.
4. Having own after –sale maintenance center, our engineer can go to overseas for installation and commissioning.
Why Choose Us
1. We Are Factory ( Not a Dealer )
We sell production machines designed together with clients, so it will be just and only for you, my dear. All machineries from Manufactory are made by ourselves, with lower price, good quality and assured full after service.
So please buy machine from factory.
2.We provide best service
Pre-sale services: enthusiasm and profession
We provide best service according to your demand, such as prophase plan, examine on the spot, process flow design , customized equipment, design solution for complete production lines and operator training etc.
In-sale services: be your assistant and servant
Send 2~12 technicians(adjustable according to the degree of automatic ) to the job site for guiding the installation and adjustment on duty, training operators and finishing the check and accept together with you. You can come to our factory to study for free.
After-sale services
We provide one year warranty to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replancements can be shipped to your right away.
To establish long term friendship, we will regularly pay return visit to customers.
