Product Description




Main Specifications.
Closed length
1.75(Bottom base included)
extended lengh
8m(Bottom base included)
net wieght
43kgs( include tripod and other accessories)
Max payload
10kgs
wind load
working rate:25m/s Max rate:35m/s
temperature
working temp:-40--+50C Storage Temp:-55--+70C
outer tube diameter
30-105mm
bottom base
Diameter:190mm Thickness: 10mm
material
Main Pole: aluminum alloy
Bottom base and accessories(except the stakes): iron steel
Pulling cord: stainless steel wire(OD:2mm)
color
the whole unit will be in army green when closed, but when extended, the main pole will be in origin color of aluminum alloy only with top 4cm of each pole section in army green color.Technology: painting
main pole in sections
Section No.         OD                     Thickness
1#                          42mm                    3.0mm
2#                          55mm                    3.0mm
3#                           69mm                   3.0mm
4#                           83mm                   3.0mm
5#                           98mm                   3.0mm
6#                           114mm                 3.0mm
7#                           132mm                 3.0mm



Catalog


we produce telescopic mast manual lifting from 2m to 45m,for payload lights,camear,ham radio,yagi ,lightning rod,or telecommunication devices.Bellow is our catalogue of usual models for your reference.

Besides,we can design different of models for ODM and OEM.



Extended  height
(m)
No. Of section
Retracted height(m)
Outer tube range(mm)
Self weight
(kg)
Max.payload
(kg)
3
3
1.0
70-90
15
20
4
3
1.5
50-80
15
30
4
3
1.0
70-90
16
20
4
3
1.6
60-80
14
10
5
4
1.65
50-80
17
10
5
5
1.2
40-90
20
15
5
5
1.5
50-90
20
60
5
6
1.7
60-130
35
100
6
5
1.7
50-90
21
10
6
6
1.5
60-130
40
100
6
7
1.3
40-130
32
60
7
7
1.8
40-105
23
30
8
8
1.5
40-130
34
20
9
7
1.8
40-105
25
40
9
7
1.8
40-105
25
30
9
7
1.8
60-160
43
100
9
7
1.9
30-90
25
5
10
7
1.95
30-90
26
10
10
7
2
30-105
31
40
12
7
2.2
30-90
28
10
12
7
2.1
30-90
28
15
12
8
2.2
40-130
44
40
15
8
2.45
30-105
33
10
15
9
2.6
30-130
40
35
15
7
2.5
70-200
200
70
16
8
2.6
30-105
35
10
18
9
2.7
30-130
47
10
18
9
3.2
30-130
48
30
18
7
3.7
50-130
47
100
20
9
2.95
30-130
55
10
20
8
3.20
40-130
58
20
22
9
3.15
30-130
58
10
25
10
3.4
30-150
72
10
25
10
3.5
80-280
90
250
25
9
3.6
40-150
71
20
30
10
3.85
30-150
84
10
35
10
4.5
40-180
130
25


Our Service


OEM/ODM service available for the buyers


Professional team for consulation, solution and designing


Complete quality control system before delivery


Multi-way fast delivery channel at buyer's option


One year free after-sale warranty after delivery


email: sales203@tjtalents.cn





Contact info





About"Talents"
Talents is a Chinese company that design, manufacture and supply a range of manual/electric/pneumatic/hydraulic operated telescopic masts and lifting devices that made of aluminum alloy tube, stainless steel tube, fiberglass tube
and carbon fiber tube.

Our masts are CE certified, we have been a golden supplier on Alibaba since 2007, we have built up
Multi-way fast delivery channels and we are supplying one year free after-sale warranty to the buyer.

We think outside the box and are continually developing new products to meet customer requirements,
what you are asking for is our motive power of task, we wish one of our products will well-meet what you demand.
