Фрезерный станок с ЧПУ 4 оси cnc фрезерный XK7124 высокой

Model name

Unit

XK7124 / XK7124A

Worktable size

mm

800

900*240(optional)

Max. Loading of worktable

kg

60

T-slot(width*qty*gap)

16*3*60

X-axis travel

mm

430

530(optional)

Y-axis travel

mm

280

Z-axis travel

mm

400

500(optional)

Distance from spindle nose to worktable

mm

60-460

Distance between spindle center and column

mm

297

Spindle speed

r/min

Low- step 100-900

High- step 900-2500

Tool holder type

BT30

Tool clamping way

Manual/Pneumatically

ATC capacity

pcs

/

Feeding moving speed

mm/min

0-2000

Fast moving speed(X/Y/Z)

mm/min

60

Positioning accuracy

mm

0.04

Repeat ability accuracy

mm

0.02

Motor power

kw

1.5

Feeding motor power(X/Y/Z)

kw

1/1/1

N/W

kg

880

Overall size(L*W*H)

mm

1600*1250*2300
