Приводы для демпфера 24 В привод моторизованного

Цена:26,00 $ - 27,00 $*

Стоимость в USD (на сегодня):Узнать

Количество:

Damper Actuator for HVAC system

Introduction:

For operation of air control dampers in HVAC system

Features:

Easy installation: can be fixed on the throttle shaft by universal shaft holde

Manual control: can have manual operation if necessary

High reliability: with the overload protection, it will stop automatically without limit switch.

Mechanical stop: with the mechanical stop inside.

Output signal: can output one switching signal within the limit of 0-100%

DS type include 1 auxiliary switch

Technical Specification:

Torque

	2 Nm
Service life	60,000 times
Damper size	0.5 sqm(m2)
Running time	30S(90°)
Supply power	AC/DC 24V
Frequency	50/60HZ
Control signal	2-point or 3- point
Direction of rotation	Manual regulation
Manual override	With
Angle of rotation	0- 90°,Max95° ,adjustable by mechanical stops
Position indication	Mechanical
Power	2W @nominal torque 0.5W @holding
Sound power level	45dB
Protection class	Ⅱ
Protection degree	IP54
Ambient temperature	-20~+50℃
ambient humidity	5-95%RH
Shaft length	50mm
Shaft diameter	Dia. 6-16mm / Square 12×12
Weight	0.52Kg
Standard	CE Requirement
